Acura TSX II (2008-2014) she lsc shd atft atpfwd Wiring diagram
This page shows the only wiring diagram for the component.she lsc shd atft atpfwd, which is found in the car Acura TSX II (2008-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram she lsc shd atft atpfwd (1 of 1)
A/T
ALTC ALTL ALTF
ATF TEMPERATURE SENSOR (UNDER TRANSMISSION)
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/YEL WIRE
ECM/PCM (LEFT SIDE OF ENGINE COMPT)
ECT SECONDARY SENSOR 1 (RIGHT REAR (LOWER RIGHT REAR OF ENGINE) OF ENGINE COMPT)
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
IAT SENSOR MAF/IAT SENSOR (ON INTAKE AIR DUCT)
LSA -
LSB
M/T
MAF SENSOR
OPSW
PCS
PNK WIRE
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
SHA SHB ATPN ATPP ATPR ATPS
SHC ATPD ATPRVS
SHE LSC SHD ATFT ATPFWD
STARTING/ CHARGING SYSTEM
TRANSMISSION RANGE SWITCH (A/T)
VG+ IAT VG-
VTS
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 2.4l (6 of 6) -> SHE LSC SHD ATFT ATPFWD
