Acura TSX II (2008-2014) sh subw gnd Wiring diagram
This page shows the only wiring diagram for the component.sh subw gnd, which is found in the car Acura TSX II (2008-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sh subw gnd (1 of 1)
10 11 12 13 14 15 16 17 18 19 20 21 22 23 PPL
3.5L
AMP MUTE
ANC FR+
ANC RR+
ANC/ACTIVE SOUND CONTROL UNIT (3.5L)
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S DOOR SPEAKER
DRIVER'S DOOR TWEETER
DRIVER'S MICU
DRIVER'S UNDER-DASH
EPS CONTROL UNIT (UNDER RIGHT SIDE OF DASH)
FL PRE-
FL SP+
FL TWSP-
FR PRE-
FR SP+
FR TWSP+
FRONT PASSENGER'S DOOR SPEAKER
FRONT PASSENGER'S DOOR TWEETER
FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
GRN WIRE
GRY WIRE
INTR LT-
LEFT REAR SPEAKER
LT BLU WIRE
LT GRN WIRE
NEP
ORG/ WIRE
PCM (LEFT SIDE OF ENGINE COMPT)
PNK PPL 8 9 WIRE
PNK WIRE
PPL
PPL 1 2 3 4 5 6 7
PPL PPL
RED WIRE
RIGHT REAR SPEAKER
RL PRE-
RL SP+
RR PRE-
RR SP-
SEDAN
SH ANC GND
SH ANCM F GND
SH ANCM R GND
SH FL GND
SH FR GND
SH RL GND
SH RR GND
SH SUBW GND
SPORT WAGON
STEREO AMPLIFIER (RIGHT SIDE OF TRUNK)
SUB WF +
SUBW PRE-
SUBWOOFER
SWD +B
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, without navigation (3 of 4) -> SH SUBW GND
