Acura TSX II (2008-2014) sedan sport wagon Wiring diagram
This page shows the only wiring diagram for the component.sedan sport wagon, which is found in the car Acura TSX II (2008-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sedan sport wagon (1 of 1)
2.4L
2.4L 3.5L
3 BACKUP SENSOR SYSTEM CONNECTOR
3.5L
A/T REVERSE DIODE A
A/T REVERSE DIODE B
A/T REVERSE RELAY
ATPR 2.4L 3.5L PCM (3.5L) ECM/PCM (2.4L) (LEFT SIDE OF ENGINE COMP)
BACKUP SENSOR BEEPER ASSEMBLY
BACKUP SENSOR CONTROL UNIT
BACKUP SENSOR IN LINE FUSE
BACKUP SENSOR SYSTEM CONNECTOR
BACKUP SENSOR SYSTEM GROUND
BEEPER (-) R MIDDLE SENS (+) L MIDDLE SENS (+)
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S UNDER- DASH FUSE/ RELAY BOX (BEHIND LEFT KICK PANEL)
FUSE 5
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY/RED WIRE
HOT IN ON OR START
LEFT BACKUP LIGHT
LEFT CORNER BACKUP SENSOR
LEFT MIDDLE BACKUP SENSOR
LT BLU WIRE
M/T A/T
NCA WIRE
ORG/ WIRE
PNK WIRE
R CORNER SENS (+) L CORNER SENS (+) POWER GROUND SENS (-)
RIGHT BACKUP LIGHT
RIGHT CORNER BACKUP SENSOR
RIGHT MIDDLE BACKUP SENSOR
SEDAN SPORT WAGON
TOP OF TRANSMISSION)
TRANSMISSION) TRANSMISSION RANGE SWITCH
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Parking assistant circuit -> SEDAN SPORT WAGON
