Acura TSX II (2008-2014) scs computer data lines system Wiring diagram
This page shows the only wiring diagram for the component.scs computer data lines system, which is found in the car Acura TSX II (2008-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram scs computer data lines system (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 PNK WIRE
ANTENNA IN
BATTERY
BATTERY FUSE
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
DRIVER'S JUNCTION BOX 1 (UNDER LEFT SIDE OF DASH)
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
ELD UNIT
FUSE 13
FUSE 15
FUSE 2 FUSE 10
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IG MAIN FUSE
LT BLU WIRE
LT GRN WIRE
LT GRN/RED WIRE
MULTI FUSE 1
MULTI FUSE 3
ORG/ WIRE
PNK PNK WIRE
PNK WIRE
PPL
RED WIRE
REMOTE STARTING CONTROL UNIT
REMOTE STARTING CONTROL UNIT GROUND GROUND +B
REMOTE STARTING CONTROL UNIT IN-LINE FUSE
REMOTE STARTING SYSTEM ANTENNA
SCS COMPUTER DATA LINES SYSTEM
STARTER
STARTER CUT RELAY 2
STARTER MOTOR
STARTER SOLENOID
STS
TOP OF TRANSMISSION)
TRANSMISSION RANGE SWITCH (TOP OF TRANSMISSION)
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
USED) (NOT
WHT WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> 3.5l, remote starting circuit (1 of 2) -> SCS COMPUTER DATA LINES SYSTEM
