Acura TSX II (2008-2014) rr wash sw Wiring diagram
This page shows the only wiring diagram for the component.rr wash sw, which is found in the car Acura TSX II (2008-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rr wash sw (1 of 1)
0) 1) OFF REAR WIPER
2) REAR WASHER
B-CAN B-CAN S-GND P-GND HI LO
B-CAN HI
B-CAN LO
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/BLK WIRE
BOX (BEHIND LEFT KICK PANEL)
BRAKE PEDAL POSITION SWITCH (ON BRAKE PEDAL SUPPORT)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S JUNCTION BOX 1 (UNDER LEFT SIDE OF DASH)
DRIVER'S MICU
DRIVER'S UNDER-DASH FUSE/RELAY
FR FR WASHER WASHER RLY CL- RLY CL-
FUSE 12
FUSE 3
FUSE 4
FUSE 5
GND ATP- (WIPER)
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HOT IN ON, START
IG 1 METER
LT GRN WIRE
PARK
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PNK WIRE
REAR WINDOW WASHER MOTOR (IN WASHER FLUID RESERVOIR)
REAR WINDOW WASHER RELAY
REAR WINDOW WIPER RELAY
REAR WINDOW WIPER/ WASHER SWITCH
RED WIRE
RED/BLU WIRE
RR WASH SW
RR WIPER
RR WIPER RLY CL-
RUN WIRE
STOP SW
TRANSMISSION
TRANSMISSION RANGE SWITCH (UNDER AUTOMATIC
TRANSMISSIONS SYSTEM
UNDER-HOOD FUSE/RELAY BOX
WINDSHIELD WASHER RELAY
WIP(AS) PASSENGER'S MICU
WIPER/WASHER SWITCH
YEL WIRE
Go to component -> Rear wiper/washer circuit -> RR WASH SW
