Acura TSX II (2008-2014) right rear right license window inner plate wiper tailgate light motor Wiring diagram
This page shows the only wiring diagram for the component.right rear right license window inner plate wiper tailgate light motor, which is found in the car Acura TSX II (2008-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear right license window inner plate wiper tailgate light motor (1 of 1)
2.4L SEDAN, 3.5L 2.4L SPORT WAGON
2.4L SPORT WAGON W/O POWER TAILGATE
BLK WIRE
BLU WIRE
CARGO AREA ACCESSORY POWER SOCKET (2.4L SPORT WAGON)
DOOR LOCK RELAY DRIVER'S DOOR UNLOCK RELAY
DOOR UNLOCK RELAY
FRONT ACCESSORY POWER SOCKET RELAY
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH
FRONT PASSENGER'S SEAT HEATER
FRONT PASSENGER'S SEAT HEATER RELAY (HIGH)
FRONT PASSENGER'S SEAT HEATER RELAY (LOW)
GAUGE CONTROL MODULE (2.4L SPORT WAGON)
GRN/WHT WIRE
HIGH MOUNT BREAK LIGHT
J/C
LEFT BACKUP LIGHT
LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH
LEFT REAR POWER WINDOW SWITCH
LEFT REAR TURN SIGNAL LIGHT
LEFT RIGHT REAR REAR SIDE SIDE MARKER MARKER LIGHT LIGHT
LEFT RIGHT TRUNK LID LICENSE LICENSE OUTER
ODS UNIT
POWER TAILGATE INSIDE BEEPER
RED WIRE
RIGHT BACKUP LIGHT
RIGHT REAR LEFT
RIGHT REAR RIGHT LICENSE WINDOW INNER PLATE WIPER TAILGATE LIGHT MOTOR
TRUNK LID OPENER SOLENOID/ LATCH SWITCH
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (5 of 6) -> RIGHT REAR RIGHT LICENSE WINDOW INNER PLATE WIPER TAILGATE LIGHT MOTOR
