Acura TSX II (2008-2014) remote starting control unit in-line fuse Wiring diagrams

1 2 3 PNK WIRE ANTENNA IN ANTI-THEFT SYSTEM BATTERY BATTERY FUSE BLK WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE BRN WIRE COMBINATION LIGHT SWITCH CONNECTOR COMPUTER DATA LINES SYSTEM DRIVER'S JUNCTION BOX 1 (UNDER LEFT SIDE OF DASH) DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) ELD UNIT FUSE FUSE 4 GND B+ GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START IMMOBILIZER KEYLESS CONTROL UNIT (UNDER STEERING COLUMN COVER) IMMOBILIZER KEYLESS CONTROL UNIT CONNECTOR JUNCTION CONNECTOR LT BLU WIRE LT GRN WIRE MULTI FUSE 1 MULTI- FUSE 3 IG MAIN FUSE ORG/ WIRE PNK 15 16 17 WIRE PNK WIRE RED WIRE REMOTE STARTING CONTROL UNIT REMOTE STARTING CONTROL UNIT GROUND REMOTE STARTING CONTROL UNIT IN-LINE FUSE RLY GND B-CAN LO B-CAN HI IMMOBILIZER SIG K-LINE SCS SHIFT LOCK SOLENOID ST RLY COIL STARTER CUT RELAY STARTER MOTOR STARTER SOLENOID STARTER REMOTE STARTING SYSTEM ANTENNA TRANSMISSION RANGE SWITCH (UNDER AUTOMATIC TRANSMISSION) UNDER- HOOD FUSE/ RELAY BOX (LEFT REAR OF ENGINE COMPT) WHT WIRE WIPER/WASHER SWITCH CONNECTOR YEL WIRE

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 PNK WIRE ANTENNA IN BATTERY BATTERY FUSE BLK WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE BRN WIRE DRIVER'S JUNCTION BOX 1 (UNDER LEFT SIDE OF DASH) DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) ELD UNIT FUSE 13 FUSE 15 FUSE 2 FUSE 10 GRY WIRE HOT AT ALL TIMES HOT IN ON OR START IG MAIN FUSE LT BLU WIRE LT GRN WIRE LT GRN/RED WIRE MULTI FUSE 1 MULTI FUSE 3 ORG/ WIRE PNK PNK WIRE PNK WIRE PPL RED WIRE REMOTE STARTING CONTROL UNIT REMOTE STARTING CONTROL UNIT GROUND GROUND +B REMOTE STARTING CONTROL UNIT IN-LINE FUSE REMOTE STARTING SYSTEM ANTENNA SCS COMPUTER DATA LINES SYSTEM STARTER STARTER CUT RELAY 2 STARTER MOTOR STARTER SOLENOID STS TOP OF TRANSMISSION) TRANSMISSION RANGE SWITCH (TOP OF TRANSMISSION) UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) USED) (NOT WHT WIRE WHT/RED WIRE YEL WIRE
