Acura TSX II (2008-2014) pnk 18 17 Wiring diagram
This page shows the only wiring diagram for the component.pnk 18 17, which is found in the car Acura TSX II (2008-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk 18 17 (1 of 1)
19 20 21 22 23 24 25 PNK WIRE
3.5L 2.4L
ACURALINK CONTROL UNIT (XM RECEIVER) (IF EQUIPPED, W/ NAVIGATION)
ACURALINK RE PROGRAMMING CONNECTOR
AUDIO UNIT (W/O NAVIGATION) AUDIO- NAVIGATION UNIT (W/ NAVIGATION)
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX (UNDER LEFT SIDE OF DASH)
CLIMATE CONTROL UNIT
COLUMN COVER)
DATA LINK CONNECTOR (DLC) (UNDER LEFT SIDE OF DASH)
DRIVER'S JUNCTION BOX 1 (3.5L) (UNDER LEFT SIDE OF DASH)
DRIVER'S JUNCTION BOX 2 (UNDER LEFT SIDE OF DASH)
FUSE 15
GAUGE CONTROL MODULE
HANDS FREELINK CONTROL UNIT (UNDER RIGHT SIDE OF DASH)
HOT AT ALL TIMES
IMMOBILIZER KEYLESS CONTROL UNIT (UNDER STEERING
LT BLU WIRE
LT PNK WIRE
ORG/ WIRE
PASSENGER'S MICU
PNK 18 17 WIRE
PNK PNK PNK PNK WIRE
PNK WIRE
RED WIRE
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
W/O NAVIGATION
W/O NAVIGATION W/ NAVIGATION
WHT WIRE
YAW RATE-LATERAL ACCELERATION SENSOR (UNDER CENTER CONSOLE)
Go to component -> Computer data lines circuit (1 of 2) -> PNK 18 17 WIRE
