Acura TSX II (2008-2014) meter driver's micu Wiring diagram
This page shows the only wiring diagram for the component.meter driver's micu, which is found in the car Acura TSX II (2008-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram meter driver's micu (1 of 1)
2.4L
3.5L
A/T REVERSE DIODE A
A/T REVERSE RELAY
AUDIO-NAVIGATION UNIT (W/ NAVIGATION)
BACKUP LIGHT SWITCH (M/T)
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BRN WIRE
CABLE REEL
CENTER JUNCTION BOX (UNDER LEFT SIDE OF DASH)
CLIMATE GLOVE CONTROL BOX UNIT LIGHT
DRIVER'S JUNCTION BOX 1 (UNDER LEFT SIDE OF DASH)
DRIVER'S JUNCTION BOX 2 (UNDER LEFT SIDE OF DASH)
DRIVER'S SEAT HEATER SWITCH
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT
ECM/PCM
EPS CONTROL UNIT
FOG LIGHT CONTROL UNIT
FROM FUSE 8 (DIAGRAM 1 OF 6)
FRONT PASSENGER'S AUDIO AIR BAG CUT-OFF UNIT INDICATOR
FRONT PASSENGER'S POWER WINDOW SWITCH
FUEL PUMP RELAY
FUSE 1
FUSE 11
FUSE 12 FUSE 13
FUSE 2
FUSE 20 (NOT USED)
FUSE 3 (FOG LIGHTS)
FUSE 4
FUSE 5
FUSE 5 (NOT USED) FUSE 21 (NOT USED
FUSE 6
FUSE 9
GAUGE CONTROL MODULE
GRN WIRE
GRN/RED WIRE
GRY WIRE
HIGH BEAM CONTROL UNIT
HOMELINK UNIT
IMMOBILIZER KEYLESS CONTROL UNIT TO DRIVER'S UNDER-DASH FUSE/RELAY BOX
J/C
KICK PANEL)
LOW BEAM CONTROL UNIT
LT BLU WIRE
METER DRIVER'S MICU
NOT USED
PASSENGER'S MICU
PCM
POWER TAILGATE CONTROL UNIT (IF EQUIPPED) (2.4L)
PPL
RED WIRE
RIGHT FRONT TURN SIGNAL/ PARKING LIGHT
RIGHT REAR POWER WINDOW RELAY
SEDAN
SMALL RLY AS CL- PASSENGER'S MICU
SPORT WAGON
STEERING VSA OFF WHEEL AUDIO REMOTE SWITCH SWITCH
TAILLIGHT CONTROL UNIT
TAILLIGHT RELAY
TO CONSOLE ACCESSORY POWER SOCKET RELAY (DIAGRAM 4 OF 6)
TO FUSE 12
TO FUSE 3 (DIAGRAM 5 OF 6)
TO PASSENGER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 6 OF 6)
TPMS CONTROL UNIT
VSA MODULATOR CONTROL UNIT
WHT WIRE
YAW RATE-LATERAL ACCELERATION SENSOR
YEL WIRE
Go to component -> Power distribution circuit (3 of 6) -> METER DRIVER'S MICU
