Acura TSX II (2008-2014) int int off off low low mist high high mist Wiring diagram
This page shows the only wiring diagram for the component.int int off off low low mist high high mist, which is found in the car Acura TSX II (2008-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram int int off off low low mist high high mist (1 of 1)
B-CAN
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S MICU
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FR WASH SW
FR WIP FR WIP B-CAN INT/LO MIST HI/LO HI LO SW SW SW
FR WIP INT VR+
FR WIPER (AS)
FUSE 3
FUSE 4
FUSE 5
GND (MICU -S)
GND (WIPER)
GRN WIRE
HOT IN ON OR START
INT INT OFF OFF LOW LOW MIST HIGH HIGH MIST
INTERMITTENT DWELL TIME CONTROLLER
METER
OFF WIND- SHIELD WASHER SWITCH
ORG/ WIRE
PARK
PNK WIRE
RUN WIRE
WASH
WHT WIRE
WIND- SHIELD WIPER SWITCH
WINDSHIELD WIPER MOTOR (UNDER LEFT SIDE HIGH OF COWL COVER)
WIP HI/LO RLY CL-
WIP INT RLY CL
WIPER/WASHER SWITCH
YEL WIRE
YEL/BLU WIRE
Go to component -> Front wiper/washer circuit (1 of 2) -> INT INT OFF OFF LOW LOW MIST HIGH HIGH MIST
