Acura TSX II (2008-2014) head auto park Wiring diagrams
This page contains all the electrical diagrams for the component. head auto park, in which he is found in the car Acura TSX II (2008-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram head auto park (1 of 2)
2.4L
AUDIO NAVIGATION UNIT (IF EQUIPPED) (UNDER RIGHT SIDE OF REAR SHELF)
AUTO B- B-
AUTO LIGHTING SENSOR
AUTOMATIC LIGHTING SENSOR/SUNLIGHT SENSOR (TOP CENTER OF DASH)
BLK WIRE
BLU WIRE
BODY CONTROLLER AREA NETWORK TRANSCEIVER
BRN WIRE
COMBINATION LIGHT SWITCH
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM (UNDER RIGHT SIDE OF DASH)
DRIVER'S JUNCTION BOX 1 (UNDER LEFT SIDE OF DASH)
DRIVER'S UNDER-DASH DRIVER'S FUSE/RELAY MICU BOX (BEHIND LEFT KICK PANEL)
FUSE 2
FUSE 6
GAUGE CONTROL MODULE
GND GND AUTO AUTO (MICU (MICU LT LT LT CAN CAN -P) -S) SIG SIP SIO LO HI
GRN WIRE
GRY WIRE
H/L
H/L SMALL OFF LOW SW SW
HEAD AUTO
HEAD AUTO PARK
HEADLIGHT SWITCH
HOT AT ALL TIMES
INDICATOR DIMMING CIRCUIT
LEFT
LEFT POWER MIRROR (IN DRIVER'S DOOR)
LEFT REAR TURN
LEFT SIDE TURN SIGNAL LIGHT
LIGHT LEFT ON IND TURN SIGNAL 3.5L IND
LT GRN WIRE
OFF
PARK OFF
PASSENGER'S MICU
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PNK WIRE
PPL
RED WIRE
RIGHT
RIGHT FRONT TURN SIGNAL/ PARKING LIGHT
RIGHT POWER MIRROR (IN FRONT PASSENGER'S DOOR)
RIGHT REAR TURN
RIGHT SIDE TURN SIGNAL LIGHT
RIGHT TURN SIGNAL IND
SIGNAL LIGHT)
TAILLIGHT CONTROL CIRCUIT
TURN SIGNAL SWITCH
TURN SIGNAL/HAZARD FLASHER CIRCUIT
TURN SIGNAL/HAZARD RELAY 2 (SOUNDER)
TURN TURN RIGHT LEFT GND SW SW (LT) SW
WARNING DRIVE CIRCUIT
WHT WIRE
Go to component -> Exterior lamps circuit, sedan (2 of 2) -> HEAD AUTO PARK
