Acura TSX II (2008-2014) fuse 11 fuse 5 Wiring diagram
This page shows the only wiring diagram for the component.fuse 11 fuse 5, which is found in the car Acura TSX II (2008-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 11 fuse 5 (1 of 1)
2.4L
3.5L
AIR BAG CUT-OFF INDICATOR
BLK WIRE
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX (UNDER LEFT SIDE OF DASH)
COMPULSORY TURNING- ON CIRCUIT
COMPUTER DATA LINES SYSTEM
CONTROL CIRCUIT
DRIVER'S JUNCTION BOX 1 (UNDER LEFT SIDE OF DASH)
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
F-CAN
FAIL SAFE CIRCUIT
FAST CONTROLLER AREA NETWORK TRANSCEIVER
FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
FUSE 11 FUSE 5
FUSE 12
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT IN ON OR START
LT BLU WIRE
NCA WIRE
ODS
ODS UNIT (LEFT SIDE OF FRONT PASSENGER'S SEAT BACK)
ORG/ WIRE
POW
PPL
RED WIRE
SEAT BELT REMINDER IND
SIDE AIR BAG CUT-OFF IND
SRS IND
TRANSCEIVER/
WARNING DRIVE CIRCUIT
WHT WIRE
WSIG
WSIP
WSOG
WSOP
YEL WIRE
Go to component -> Supplemental restraints circuit (2 of 3) -> FUSE 11 FUSE 5
