Acura TSX II (2008-2014) fuel ppl 1 3 16 15 gauge sending unit Wiring diagrams
This page contains all the electrical diagrams for the component. fuel ppl 1 3 16 15 gauge sending unit, in which he is found in the car Acura TSX II (2008-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram fuel ppl 1 3 16 15 gauge sending unit (1 of 2)
B-CAN
B-CAN B-CAN LO HI
B-CAN LO HI
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BRN WIRE
CABLE REEL (CONNECTOR B: UNDER STEERING COLUMN COVER)
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR SWITCH (LEFT "B"
DRIVER'S JUNCTION BOX 1 (UNDER LEFT SIDE OF DASH)
ECM/PCM (LEFT SIDE OF ENGINE COMPT)
FR DR SW R
FRONT PASSENGER'S DOOR SWITCH (RIGHT "B"
FUEL PPL 1 3 16 15 GAUGE SENDING UNIT
FUEL TANK UNIT (TOP OF FUEL TANK)
FUSE 15
FUSE 5
FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
GRN WIRE
GRN/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LEFT REAR DOOR SWITCH (LEFT "C" PILLAR)
LT GRN WIRE
M/T
NEXT SWITCH
OIL PRESSURE SWITCH (UNDER RIGHT FRONT OF ENGINE)
ORG/ WIRE
PARKING BRAKE SWITCH (UNDER CENTER CONSOLE, ON PARKING BRAKE LEVER)
PASSENGER'S MICU
PASSENGER'S UNDER-DASH
PILLAR)
PNK WIRE
POWER SEAT CONTROL UNIT (W/ MEMORY) (UNDER DRIVER'S SEAT)
PPL
PPL 1 2
RED WIRE
RIGHT REAR DOOR SWITCH (RIGHT "C" PILLAR)
RR DOOR SW R
SELECT/ PREVIOUS RESET SWITCH SWITCH
SELECT/RESET INFORMATION SWITCH
STEERING WHEEL)
SW IN CAN H CAN L COMPUTER DATA LINES SYSTEM
TRUNK LID OPENER SOLENOID/LATCH SWITCH (SEDAN) (CENTER REAR OF TRUNK LID)
TRUNK RR DR SW SW L
TRUNK, TAILGATE, FUEL DOORS SYSTEM
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
WHT WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> 2.4l, instrument cluster circuit (2 of 2) -> FUEL PPL 1 3 16 15 GAUGE SENDING UNIT
