Acura TSX II (2008-2014) engine mount control solenoid valve Wiring diagram
This page shows the only wiring diagram for the component.engine mount control solenoid valve, which is found in the car Acura TSX II (2008-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine mount control solenoid valve (1 of 1)
2.4L
3.5L
ACURALINK CONTROL UNIT (XM RECEIVER) (IF EQUIPPED)
ALTERNATOR
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BOX (UNDER LEFT SIDE OF DASH)
BRAKE PEDAL POSITION SWITCH
BRN WIRE
CENTER JUNCTION
CMP SENSOR A
DOOR LOCK RELAY
ELD UNIT
ELECTRICAL COMPASS
ELECTRICAL COMPASS UNIT (IF EQUIPPED)
ENGINE MOUNT CONTROL SOLENOID VALVE
EVAP ALTERNATOR CANISTER PURGE VALVE
EVAP CANISTER PURGE VALVE
FROM DRIVER'S JUNCTION BOX 1 (DIAGRAM 3 OF 6)
FROM FUSE 24 (DIAGRAM 4 OF 6)
FROM FUSE 9 (DIAGRAM 3 OF 6)
FROM WIPER MOTOR FUSE (DIAGRAM 4 OF 6)
FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
FUSE 12
FUSE 22 FUSE 25
FUSE 7
GRN WIRE
J/C
LEFT REAR DRIVER'S DOOR POWER DOOR UNLOCK WINDOW UNLOCK RELAY RELAY RELAY
MAIN FAN MOTOR FUSE
METER PASSENGER'S MICU
MULTI- FUSE 3 SUB FAN MOTOR FUSE (3.5L)
ODS UNIT
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PCM
PPL
RADIATOR FAN RELAY
REAR OF ENGINE COMPT)
REVERSE LOCKOUT SOLENOID (M/T)
SECONDARY
SPORT WAGON
SRS UNIT
TRUNK LID OPENER RELAY
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (6 of 6) -> ENGINE MOUNT CONTROL SOLENOID VALVE
