Acura TSX II (2008-2014) driver's micu b-can b-can rly lo hi Wiring diagram
This page shows the only wiring diagram for the component.driver's micu b-can b-can rly lo hi, which is found in the car Acura TSX II (2008-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's micu b-can b-can rly lo hi (1 of 1)
2.4L
3.5L
3.5L 2.4L
A/C COMPRESSOR CLUTCH RELAY (2.4L)
B CAN B CAN HI LO
BLK WIRE
BLOWER MOTOR RELAY
BLU WIRE
BRN/WHT WIRE
CLIMATE CONTROL UNIT
COMPUTER DATA LINES SYSTEM
DEFOGGER NOISE CONDENSER GND (LEFT "C" PILLAR) REAR WINDOW DEFOGGER IND
DRIVER'S MICU B-CAN B-CAN RLY LO HI
DRIVER'S UNDER- DASH FUSE/ RELAY BOX (BEHIND LEFT KICK PANEL)
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FUSE 16
FUSE 4
GRN WIRE
HOT AT ALL TIMES
HOT IN ON
LEFT "C" PILLAR)
LT GRN WIRE
PNK WIRE
REAR WINDOW
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER NOISE CONDENSER
REAR WINDOW DEFOGGER RELAY
REAR WINDOW DEFOGGER SWITCH
RR DEF
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
Go to component -> Rear defogger circuit -> DRIVER'S MICU B-CAN B-CAN RLY LO HI
