Acura TSX II (2008-2014) dr b-can sw l hi Wiring diagram
This page shows the only wiring diagram for the component.dr b-can sw l hi, which is found in the car Acura TSX II (2008-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dr b-can sw l hi (1 of 1)
2.4L
3 4 B-CAN LO B-CAN HI PNK WIRE
3.5L
AMBIENT LIGHT
ANTENNA
AUTO CLOSE
AUTO MOONROOF MOTOR UART
AUTO OPEN
B-CAN
B-CAN HI
B-CAN LO
BLK WIRE
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX (UNDER LEFT SIDE OF DASH)
CLOSE
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM FRONT PASSENGER'S DOOR SWITCH (RIGHT "B" PILLAR)
CONTROL UNIT)
DR B-CAN SW L HI
DR HI SW L
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/ KEY CYLINDER SWITCH
DRIVER'S DOOR SWITCH (LEFT "B" PILLAR)
DRIVER'S JUNCTION BOX 2 (UNDER LEFT SIDE OF DASH)
DRIVER'S MICU
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FUSE 20
FUSE 5
GRN WIRE
GRY WIRE
HALL SENSOR
HOT AT ALL TIMES
HOT IN ON OR START
IMMOBILIZER KEYLESS CONTROL UNIT (UNDER STEERING COLUMN COVER)
KICK PANEL)
LOCK
LT BLU WIRE
LT GRN WIRE
MOONROOF CLOSE RELAY
MOONROOF CONTROL UNIT/MOTOR (CENTER OF ROOF)
MOONROOF OPEN RELAY
MOONROOF SWITCH (3.5L) INTERIOR LIGHT/ MOONROOF SWITCH (2.4L)
OPEN OFF CLOSE
ORG/ WIRE
PASSENGER'S MICU
PASSENGER'S UNDER-DASH FUSE/RELAY BOX (BEHIND RIGHT
PLSB PLSA SVCC
PNK WIRE
POWER WINDOW MASTER SWITCH
PPL
RED WIRE
TILT
UART
UNLCK DRIVER'S DOOR KEY CYLINDER SWITCH
UNLOCK
Go to component -> Power top/sunroof circuit -> DR B-CAN SW L HI
