Acura TSX II (2008-2014) computer data lines system w/o navigation Wiring diagrams
This page contains all the electrical diagrams for the component. computer data lines system w/o navigation, in which he is found in the car Acura TSX II (2008-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
computer data lines system w/o navigation wiring diagram (1 of 2)
+B BACK
5 1 DOOR LOCK ACTUATOR
AUDIO- NAVIGATION UNIT
B-CAN HI
B-CAN LO
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES PNK WIRE
COMPUTER DATA LINES SYSTEM (UNDER RIGHT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM W/O NAVIGATION
CONTROL UNIT)
CYLINDER SWITCH (REAR OF DRIVER'S DOOR)
DL AS LOCK RLY CL- B- B- FR DR GND CAN CAN SCTY LOCK SW R LOW (MICU-P) HI RADIO
DL AS UNLOCK RLY CL-
DOOR LOCK RELAY
DOOR LOCK SWITCH
DOOR LOCK SWITCH LOCK LIGHT
DOOR LOCK SWITCH UNLOCK LIGHT
DOOR UNLOCK RELAY
DRIVER'S DOOR KEY CYLINDER SWITCH
DRIVER'S DOOR LOCK ACTUATOR/KNOB SWITCH/KEY
DRIVER'S DOOR LOCK KNOB SWITCH
FRONT PASSENGER'S DOOR SWITCH (RIGHT "B" PILLAR)
FRONT PASSENGER'S POWER WINDOW SWITCH
FUSE 10
FUSE 13
FUSE 15
GRN WIRE
GRY WIRE
HORN RELAY
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE 10
KEYLESS BUZZER (BEHIND LEFT SIDE OF FRONT BUMPER)
KNOB DOOR LOCK UN LK SWITCH UNLOCK LIGHT VMP AS
KNOB LOCK CONTROL UNIT
KNOB UNLOCK
LOCK
LOCK 10 8 ACTUATOR
LOCK ACTUATOR
LOW HORN, HIGH HORN
LT GRN WIRE
NAVIGATION UNIT AUDIO UNIT (UNDER RIGHT SIDE OF REAR SHELF)
OF DASH)
OF ENGINE COMPT)
ORG/ WIRE
PASSENGER'S MICU
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PNK LT WIRE
POWER WINDOW MASTER SWITCH
RED WIRE
RIGHT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH (REAR OF RIGHT REAR DOOR)
RIGHT REAR DOOR LOCK KNOB SWITCH
RIGHT REAR DOOR SWITCH
RR DR KEY SW R BUZZER METER UP
SCTY SCTY 1 SCTY 2
SYSTEM (UNDER LEFT SIDE
UART
UART DOOR LOCK SWITCH LOCK LIGHT
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR
UNLOCK
VBU
VMP DR
W/ NAVIGATION
WHT WIRE
YEL WIRE
Go to component -> Forced entry circuit (2 of 2) -> COMPUTER DATA LINES SYSTEM W/O NAVIGATION
