Acura TSX II (2008-2014) charging system indicator Wiring diagrams
This page contains all the electrical diagrams for the component. charging system indicator, in which he is found in the car Acura TSX II (2008-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram charging system indicator (1 of 2)
A/T
ALTERNATOR IG
BATTERY
BATTERY FUSE
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BRAKE PEDAL POSITION SWITCH (ON BRAKE PEDAL SUPPORT)
BRN WIRE
CAN CONTROLLER
CENTER JUNCTION BOX (UNDER LEFT SIDE OF DASH)
CHARGING SYSTEM INDICATOR
COMM COMM ALT ALT ALT UNIT SIG SIG FR SIG HIGH INPUT LOW SIG SIG
DRIVER'S JUNCTION BOX 1
DRIVER'S UNDER-DASH FUSE/RELAY BOX
ECM/PCM (LEFT SIDE OF ENGINE COMPT)
ELD
ELD UNIT
FAST CONTROLLER AREA NETWORK TRANSCEIVER
FUSE 5
FUSE 7
GAUGE CONTROL MODULE
GRN WIRE
HOT IN ON OR START
MULTI FUSE 1
POWER DISTRIBUTION SYSTEM
RED WIRE
STARTING CIRCUIT
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
WARNING DRIVE CIRCUIT
WHT WIRE
YEL WIRE
Go to component -> 2.4l, charging circuit -> CHARGING SYSTEM INDICATOR
Wiring diagram charging system indicator (2 of 2)
ALT ALT ALT VBSOL
ALTERNATOR IG
BATTERY
BATTERY FUSE
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
CHARGING SYSTEM INDICATOR
COMPUTER DATA LINES SYSTEM
CONTROL CIRCUITS
DRIVER JUNCTION BOX 1 (UNDER LEFT SIDE OF DASH)
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT
ELD UNIT
F-CANH ELD
F-CANL
FAST CONTROLLER AREA NETWORK TRANSCEIVER
FUSE 5
FUSE 7
GAUGE CONTROL MODULE
GRN WIRE
HOT IN ON OR START
KICK PANEL)
MULTI FUSE 1
PCM (LEFT SIDE OF ENGINE COMPT)
POWER DISTRIBUTION SYSTEM
REAR OF ENGINE COMPT)
RED WIRE
STARTING CIRCUIT
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> 3.5l, charging circuit -> CHARGING SYSTEM INDICATOR
