Acura TSX II (2008-2014) bluetooth tranceiver Wiring diagrams
This page contains all the electrical diagrams for the component. bluetooth tranceiver, in which he is found in the car Acura TSX II (2008-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
bluetooth tranceiver wiring diagram (1 of 2)
23 24 25 26 27 28 29 30 PPL
AUDIO L+
AUDIO R-
AUDIO SH
B-CAN HI
B-CAN LO
BLK WIRE
BLU WIRE
BLUETOOTH TRANCEIVER
BRN WIRE
COMPUTER DATA LINES SYSTEM
GA AUDIO SH
GA-BUS SH
GA-BUS-
GANET AUDIO L -
GANET AUDIO R -
GANET BUS SH
GANET BUS-
GND SH
GRN WIRE
GRY WIRE
HANDSFREELINK CONTROL UNIT (UNDER RIGHT SIDE
HFL MUTE
HFL STRG SW
HIP/HFL COMMSH
LT BLU WIRE
LT GRN WIRE
MIC -
MIC SH
MIC SIG
NCA WIRE
OF DASH)
PNK WIRE
PPL
PPL 13 14 15
PPL 13 14 15 16
RED WIRE
SAT/TER
SATELLITE SIGNAL ANTENNA
SYS ACC
TELM SIG -
TELM SIG SH
W/ ACURA LINK
W/O ACURA LINK
WHT WIRE
XM ANTENNA
XM RECEIVER (IF EQUIPPED) (RIGHT "C" PILLAR)
YEL WIRE
Go to component -> Navigation circuit (5 of 7) -> BLUETOOTH TRANCEIVER
bluetooth tranceiver wiring diagram (2 of 2)
23 24 25 26 27 28 29 30 PPL
AUDIO L+
AUDIO R-
AUDIO SH
B-CAN HI
B-CAN LO
BLK WIRE
BLU WIRE
BLUETOOTH TRANCEIVER
BRN WIRE
COMPUTER DATA LINES SYSTEM
GA AUDIO SH
GA-BUS SH
GA-BUS-
GANET AUDIO L -
GANET AUDIO R -
GANET BUS SH
GANET BUS-
GND SH
GRN WIRE
GRY WIRE
HANDSFREELINK CONTROL UNIT (UNDER RIGHT SIDE
HFL MUTE
HFL STRG SW
HIP/HFL COMMSH
LT BLU WIRE
LT GRN WIRE
MIC -
MIC SH
MIC SIG
NCA WIRE
OF DASH)
PNK WIRE
PPL
PPL 13 14 15
PPL 13 14 15 16
RED WIRE
SAT/TER
SATELLITE SIGNAL ANTENNA
SYS ACC
TELM SIG -
TELM SIG SH
W/ ACURA LINK
W/O ACURA LINK
WHT WIRE
XM ANTENNA
XM RECEIVER (IF EQUIPPED) (RIGHT "C" PILLAR)
YEL WIRE
Go to component -> Radio circuit, with navigation (5 of 7) -> BLUETOOTH TRANCEIVER
