Acura TSX II (2008-2014) b can b can hi lo Wiring diagrams
This page contains all the electrical diagrams for the component. b can b can hi lo, in which he is found in the car Acura TSX II (2008-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram b can b can hi lo (1 of 2)
27 33 35 UART B-CAN LO B-CAN HI
B CAN B CAN HI LO
BLK WIRE
BLU WIRE
CENTER JUNCTION BOX (UNDER LEFT SIDE OF DASH)
CLIMATE CONTROL UNIT GND
COMPUTER DATA LINES SYSTEM
CONTROL UNIT POWER WINDOW MASTER SWITCH
DEFOGGER LEFT POWER MIRROR (IN DRIVER'S DOOR)
DEFOGGER RIGHT POWER MIRROR (IN FRONT PASSENGER'S DOOR)
DRIVER'S UNDER-DASH
FRONT PASSENGER'S POWER WINDOW SWITCH
FUSE 13
FUSE 16
FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
GRN WIRE
HEAT (+)
HOT AT ALL TIMES
HOT IN ON
LT GRN WIRE
OF DASH)
ORG/ WIRE
PASSENGER'S UNDER-DASH
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
REAR POWER MIRROR DEFOGGER IND
REAR POWER MIRROR DEFOGGER SWITCH
UART
VMPAS
Go to component -> Heated mirrors circuit -> B CAN B CAN HI LO
Wiring diagram b can b can hi lo (2 of 2)
2.4L
3.5L
3.5L 2.4L
A/C COMPRESSOR CLUTCH RELAY (2.4L)
B CAN B CAN HI LO
BLK WIRE
BLOWER MOTOR RELAY
BLU WIRE
BRN/WHT WIRE
CLIMATE CONTROL UNIT
COMPUTER DATA LINES SYSTEM
DEFOGGER NOISE CONDENSER GND (LEFT "C" PILLAR) REAR WINDOW DEFOGGER IND
DRIVER'S MICU B-CAN B-CAN RLY LO HI
DRIVER'S UNDER- DASH FUSE/ RELAY BOX (BEHIND LEFT KICK PANEL)
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FUSE 16
FUSE 4
GRN WIRE
HOT AT ALL TIMES
HOT IN ON
LEFT "C" PILLAR)
LT GRN WIRE
PNK WIRE
REAR WINDOW
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER NOISE CONDENSER
REAR WINDOW DEFOGGER RELAY
REAR WINDOW DEFOGGER SWITCH
RR DEF
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
Go to component -> Rear defogger circuit -> B CAN B CAN HI LO
