Acura TSX II (2008-2014) acc cut relay Wiring diagrams
This page contains all the electrical diagrams for the component. acc cut relay, in which he is found in the car Acura TSX II (2008-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram acc cut relay (1 of 3)
ACC CUT RELAY
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION SWITCH
COMBINATIOON LIGHT SWITCH CONNECTOR
COMPUTER DATA LINES SYSTEM
DRIVER'S MICU FR WIP GND
DRIVER'S UNDER DASH FUSE/ RELAY BOX DRIVER'S UNDER DASH FUSE/ RELAY BOX
DRIVER'S UNDER- DASH FUSE/ RELAY BOX
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FUSE 15
FUSE 8
GRN WIRE
GRY WIRE
H/L OFF GND SW SW
HEADLIGHT SWITCH 0=OFF 1=PARK 2=AUTO 3=HEAD
IGNITION SWITCH
INTERMITTENT DWELL TIME CONTROLLER
LOCK
LT BLU WIRE
LT GRN WIRE
LT GRN/RED WIRE
ORG/ WIRE
PCM (LEFT SIDE OF ENGINE COMPT)
PNK PNK STRLD SLS F-CAN H F-CAN L WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
PPL STRLY STS
RED WIRE
SMALL LOW
STARTER CUT RELAY 1
WHT WIRE
WHT/RED WIRE
WIPER/WASHER SWITCH
WIPER/WASHER SWITCH CONNECTOR
YEL WIRE
Go to component -> 3.5l, remote starting circuit (2 of 2) -> ACC CUT RELAY
Wiring diagram acc cut relay (2 of 3)
ACC CUT RELAY
BATTERY
BATTERY FUSE
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
ELD UNIT
FUSE 13
FUSE 8
GRN WIRE
IGNITION SWITCH
LOCK
LT GRN WIRE
LT PPL
LT USED)
MULTI FUSE 1
MULTI- FUSE 3 IG MAIN FUSE
PCM STS CAN STRLY STRLD (LEFT SIDE OF ENGINE COMPT)
PPL PNK WIRE
PPL PPL
RED WIRE
STARTER
STARTER CUT RELAY 1
STARTER CUT RELAY 2
STARTER MOTOR
STARTER SOLENOID
TOP OF TRANSMISSION)
TRANSMISSION RANGE SWITCH
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> 3.5l, starting circuit -> ACC CUT RELAY
Wiring diagram acc cut relay (3 of 3)
2.4L
2.4L 3.5L
3.5L
3.5L, 2.4L W/ MEMORY
ACC CUT RELAY
AS LIGHT MAIN FUSE
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BOX (LEFT REAR OF ENGINE COMPT)
CARGO AREA ACCESSORY POWER SOCKET
CARGO AREA ACCESSORY POWER SOCKET RELAY (SPORT WAGON) (UNDER LEFT SIDE OF DASH)
CENTER JUNCTION BOX (UNDER LEFT SIDE OF DASH)
CONSOLE ACCESSORY POWER SOCKET
CONSOLE ACCESSORY POWER SOCKET RELAY (UNDER LEFT SIDE OF DASH)
DR FUSE BOX
DR FUSE BOX (2.4L)
DR LIGHT MAIN FUSE
FROM ELD UNIT (DIAGRAM 1 OF 6)
FROM FUSE 29 (DIAGRAM 2 OF 6)
FROM PASSENGER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 1 OF 6)
FROM PASSENGER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 3 OF 6)
FRONT ACCESSORY POWER SOCKET
FRONT ACCESSORY POWER SOCKET RELAY
FUSE 14 (NOT USED)
FUSE 19
FUSE 20
FUSE 21
FUSE 23
FUSE 24
FUSE 31 (NOT USED)
GRN WIRE
IG MAIN FUSE
LT BLU WIRE
LT GRN WIRE
MOONROOF CONTROL UNIT/ MOTOR
MULTI FUSE 3
NOT USED NOT USED
OF DASH)
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PCM
PNK WIRE
POWER IGNITION WINDOW KEY MASTER SWITCH/ SWITCH KEY LIGHT (3.5L)
PPL
PPL (BEHIND CENTER OF DASH)
PPL 2.4L W/O MEMORY
PPL PPL
PPL PPL 2.4L
PPL PPL PPL DRIVER'S JUNCTION BOX 2 (UNDER LEFT SIDE OF DASH) PPL
PPL/ PPL/ PPL/
RED WIRE
RELAY (DIAGRAM PPL 5 OF 6)
STARTER CUT RELAY 1
STARTER CUT RELAY 2
STRLY
TO FUSE 17 (DIAGRAM 5 OF 6) FUSE 18
TO FUSE 22 (DIAGRAM 6 OF 6)
TO IGNITION SWITCH (DIAGRAM 5 OF 6)
TO MAIN FAN MOTOR FUSE (DIAGRAM 6 OF 6)
TO PPL RELAY (DIAGRAM 3.5L 2.4L 5 OF 6)
TO STARTER CUT RELAY 1
TRANSMISSION RANGE SWITCH
UNDER-HOOD FUSE/RELAY
WHT WIRE
WINDSHIELD WIPER RELAY
WIPER MOTOR FUSE
YEL WIRE
Go to component -> Power distribution circuit (4 of 6) -> ACC CUT RELAY
