Wiring diagram 25 29 3 4 5 32 30 31 35 vmp as uart ud com lr vlse vref hise gnd (1 of 2)
25 29 3 4 5 32 30 31 35 VMP AS UART UD COM LR VLSE VREF HISE GND
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BRN WIRE
CENTER JUNCTION BOX (UNDER LEFT SIDE OF DASH)
COM
CONTROL UNIT)
DEFOGGER
DEFOGGER SYSTEM
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FRONT PASSENGER'S POWER WINDOW SWITCH
FUSE 13
FUSE 16
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
J/C
LEFT POWER MIRROR
LEFT PPL SWITCH 2 RIGHT
LEFT SWITCH 3
LEFT/ RIGHT MOTOR (IN DRIVER'S DOOR)
LEFT/ RIGHT MOTOR UP/ DOWN MOTOR
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
ORG/WHT WIRE
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PNK WIRE
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
PPL
RED WIRE
RIGHT POWER MIRROR (IN FRONT PASSENGER'S DOOR)
SWING (HORIZONTAL)
SWITCH 1 RIGHT
TILT (VERTICAL)
TURN LIGHT SIGNAL
TURN LIGHT SIGNAL UP/ DOWN MOTOR
UART
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> 2.4l, power mirrors circuit -> 25 29 3 4 5 32 30 31 35 VMP AS UART UD COM LR VLSE VREF HISE GND
Wiring diagram 25 29 3 4 5 32 30 31 35 vmp as uart ud com lr vlse vref hise gnd (2 of 2)
25 29 3 4 5 32 30 31 35 VMP AS UART UD COM LR VLSE VREF HISE GND
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BRN WIRE
CENTER JUNCTION BOX (UNDER LEFT SIDE OF DASH)
COM
CONTROL UNIT)
DEFOGGER
DEFOGGER SYSTEM
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FRONT PASSENGER'S POWER WINDOW SWITCH
FUSE 13
FUSE 16
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
J/C
LEFT POWER MIRROR
LEFT PPL SWITCH 2 RIGHT
LEFT SWITCH 3
LEFT/ RIGHT MOTOR (IN DRIVER'S DOOR)
LEFT/ RIGHT MOTOR UP/ DOWN MOTOR
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
ORG/WHT WIRE
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PNK WIRE
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
PPL
RED WIRE
RIGHT POWER MIRROR (IN FRONT PASSENGER'S DOOR)
SWING (HORIZONTAL)
SWITCH 1 RIGHT
TILT (VERTICAL)
TURN LIGHT SIGNAL
TURN LIGHT SIGNAL UP/ DOWN MOTOR
UART
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> 3.5l, power mirrors circuit -> 25 29 3 4 5 32 30 31 35 VMP AS UART UD COM LR VLSE VREF HISE GND
