Fog lamp circuit, accessory for Acura TSX I (2003-2008)
Fog lamp circuit, accessory
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BLU/YEL WIRE
COMBINATION LIGHT SWITCH
COMBINATION SWITCH CONTROL UNIT
COMPARTMENT)
FOG LIGHT RELAY (AT LEFT SIDE OF ENGINE
FOG LIGHT SWITCH
FUSE 10
FUSE 21
FUSE 7
HOT AT ALL TIMES
HOT IN ON OR START
JUNCTION CONNECTOR
LEFT FOG LIGHT
LT GRN WIRE
NOT USED
ON OFF
RED WIRE
RELAY CONTROL MODULE CONTROL BLOCK
RIGHT FOG LIGHT
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
WIPER/ WASHER SWITCH
YEL WIRE
YEL/RED WIRE
