Exterior lamps circuit for Acura TSX I (2003-2008)

BLK WIRE BLK/LT GRN WIRE BLU WIRE BRN WIRE COMBINATION LIGHT SWITCH COMBINATION SWITCH CONTROL UNIT FUSE 16 FUSE 21 FUSE 7 GAUGE CONTROL MODULE GRN WIRE GRN/RED WIRE GRN/YEL WIRE HAZARD WARNING SWITCH HOT AT ALL TIMES HOT IN ON OR START JUNCTION CONNECTOR LEFT FRONT PARKING LIGHT LEFT FRONT TURN SIGNAL LIGHT LEFT REAR TURN SIGNAL LIGHT LEFT SIDE TURN SIGNAL LIGHT LEFT TURN SIGNAL INDICATOR LT GRN WIRE MICU ORG/WHT WIRE PNK WIRE PPL REAR JUNCTION BLOCK RED WIRE RED/BLK WIRE RED/BLU WIRE RIGHT FRONT PARKING LIGHT RIGHT FRONT TURN SIGNAL LIGHT RIGHT REAR TURN SIGNAL LIGHT RIGHT SIDE TURN SIGNAL LIGHT RIGHT TURN SIGNAL INDICATOR SUPPLEMENTAL RETRAINTS SYSTEM TURN SIGNAL LIGHT SWITCH TURN SIGNAL/ HAZARD RELAY UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) WHT WIRE WHT/BLK WIRE WIPER/WASHER SWITCH YEL WIRE

BLK WIRE BLK/RED WIRE BRAKE PEDAL POSITION SWITCH (ON BRAKE PEDAL SUPPORT) COMBINATION LIGHT SWITCH COMBINATION SWITCH CONTROL UNIT CONTROL BLOCK ECM/PCM (UNDER MIDDLE OF DASH) FUSE 4 GRN/WHT WIRE HEADLIGHT SWITCH 0) OFF 1) PARK 2) HEAD HIGH MOUNT BRAKE LIGHT HOT AT ALL TIMES JUNCTION CONNECTOR LEFT BRAKE LIGHT/ TAILLIGHT LEFT INNER TAILLIGHT LEFT REAR SIDE MARKER LIGHT LICENSE PLATE LIGHT MICU NAVIGATION SYSTEM, MEMORY SYSTEM REAR JUNCTION BLOCK RED WIRE RED/BLK WIRE RELAY CONTROL MODULE RIGHT BRAKE LIGHT/ TAILLIGHT RIGHT INNER TAILLIGHT RIGHT REAR SIDE MARKER LIGHT TAILLIGHT RELAY UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) W/ REAR SPOILER W/O REAR SPOILER WHT WIRE WHT/BLK WIRE WIPER/WASHER SWITCH
