Cooling fan circuit for Acura TSX I (2003-2008)

Cooling fan circuit

Get access

A/C CONDENSER FAN MOTOR (AT LEFT FRONT OF ENGINE) AIR CONDITIONING SYSTEM BLK WIRE BLK/YEL WIRE BLU WIRE CANL - CONDENSER FAN RELAY ECM/PCM (UNDER MIDDLE OF DASH) (FANC) FAN CTRL ECT SENSOR 2 (BOTTOM LEFT SIDE OF RADIATOR) FUSE 11 FUSE 30 FUSE 9 GRN WIRE HOT AT ALL TIMES HOT IN ON RADIATOR FAN MOTOR (AT LEFT FRONT OF ENGINE COMPT) RADIATOR FAN RELAY RED WIRE UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE
