Data link connector circuit for Acura TSX I (2003-2008)
Data link connector circuit
BLK WIRE
BLU WIRE
BRN WIRE
CHK IN K- LINE
DATA LINK CONNECTOR (DLC) (AT LOWER LEFT OF DASH, ABOVE THE KICK PANEL)
DLC
ECM/PCM (UNDER MIDDLE OF DASH)
FUSE 8
GRN/RED WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
IMMOBILIZER CONTROL UNIT -RECEIVER (IN STEERING COLUMN COVER)
LT GRN WIRE
MES CONNECTOR
MICU
MULTIPLEX CONTROL INSPECTION CONNECTOR
NAVIGATION 2 1 SERVICE DIAG + DIAG - CHECK CONNECTOR (IN TRUNK, UNDER RIGHT
NAVIGATION UNIT (IN TRUNK, UNDER MIDDLE OF REAR SHELF)
SIDE OF REAR SHELF)
SRS UNIT (BEHIND MIDDLE OF DASH)
VSA MODULATOR CONTROL UNIT (AT RIGHT SIDE OF ENGINE COMPT)
WHT WIRE
WHT/GRN WIRE
