Acura TSX I (2003-2008) trunk license plate light lid opener switch Wiring diagram
This page shows the only wiring diagram for the component.trunk license plate light lid opener switch, which is found in the car Acura TSX I (2003-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trunk license plate light lid opener switch (1 of 1)
BLK WIRE
DOOR MULTIPLEX CONTROL UNIT
DRIVER'S SEAT BELT SWITCH
DRIVER'S SEAT SEAT BACK HEATER
FRONT PASSENGER'S
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FRONT PASSENGER'S SEAT BELT SWITCH
FRONT PASSENGER'S SWITCH
FUEL TANK UNIT
HIGH MOUNT BRAKE LIGHT
LEFT BACKUP LIGHT
LEFT INNER TAILLIGHT
LEFT POWER MIRROR
LEFT REAR DOOR LOCK KNOB SWITCH
LEFT REAR POWER WINDOW SWITCH
LEFT REAR SIDE MARKER LIGHT
LEFT REAR SWITCH
LEFT REAR TURN SIGNAL LIGHT LEFT BRAKE LIGHT/ TAILLIGHT
LEFT SIDE TURN SIGNAL LIGHT
MAIN SWITCH
MICU
MULTIPLEX CONTROL UNIT INSPECTION CONNECTOR
NAVIGATION UNIT (IF EQUIPPED)
NCA WIRE
NOISE CONDENSER
ODS UNIT
POWER MIRROR SWITCH
POWER SEAT CONTROL UNIT
POWER WINDOW MASTER SWITCH
PPL
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER COIL
RIGHT BACKUP LIGHT
RIGHT BRAKE LIGHT/ TAILLIGHT RIGHT REAR TURN SIGNAL LIGHT
RIGHT INNER HIGH MOUNT BRAKE LIGHT
RIGHT REAR DOOR LOCK KNOB SWITCH
RIGHT REAR POWER WINDOW SWITCH
RIGHT REAR SIDE MARKER LIGHT
RIGHT REAR SWITCH
SEAT HEATER
TAILLIGHT
TRUNK LATCH SWITCH
TRUNK LICENSE PLATE LIGHT LID OPENER SWITCH
TURN SIGNAL/ HAZARD RELAY
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
WHT/BLU WIRE
YEL WIRE
Go to component -> Ground distribution circuit (4 of 4) -> TRUNK LICENSE PLATE LIGHT LID OPENER SWITCH
