Acura TSX I (2003-2008) side air bag cut-off indicator Wiring diagram
This page shows the only wiring diagram for the component.side air bag cut-off indicator, which is found in the car Acura TSX I (2003-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram side air bag cut-off indicator (1 of 1)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
BRN/YEL WIRE
CABLE REEL
DATA LINK CONNECTOR (DLC) (AT LOWER LEFT OF DASH, ABOVE KICK PANEL)
DRIVER'S AIR BAG SECOND INFLATOR DRIVER'S AIR BAG FIRST INFLATOR
DRIVER'S SEAT BELT SWITCH (UNDER DRIVER'S SEAT)
FRONT PASSENGER'S AIR BAG FIRST INFLATOR (BEHIND GLOVE BOX)
FRONT PASSENGER'S AIR BAG SECOND INFLATOR (BEHIND GLOVE BOX)
FUSE 10
FUSE 21
FUSE 22
GAUGE CONTROL MODULE
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
HOT IN ON OR START
JUNCTION
JUNCTION CONNECTOR
LBSC
LEFT FRONT IMPACT SENSOR (BEHIND LEFT SIDE OF BUMPER)
LT GRN WIRE
LT GRN/BLK WIRE
MES CONNECTOR
MICU
PNK (OR BLU) WIRE
PNK WIRE
PNK/BLU WIRE
PWR SUPPLY CIRCUIT
RED WIRE
RIGHT FRONT IMPACT SENSOR
SEAT BELT BUCKLED
SEAT BELT UNBUCKLED
SIDE AIR BAG CUT-OFF INDICATOR
SRS IND
SRS INDICATOR CIRCUIT
SRS UNIT (BEHIND MIDDLE OF DASH)
STEERING WHEEL)
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
WHT WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (1 of 3) -> SIDE AIR BAG CUT-OFF INDICATOR
