Acura TSX I (2003-2008) side air bag cut-off ind Wiring diagram
This page shows the only wiring diagram for the component.side air bag cut-off ind, which is found in the car Acura TSX I (2003-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram side air bag cut-off ind (1 of 1)
A/T GEAR POSITION IND DRIVE CIRCUIT
ABS IND.
BEEPER
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROLLER AREA NETWORK TRANSCEIVER
BRAKE SYSTEM IND
BRN WIRE
CANADA
CHARGING SYSTEM IND
CRUISE CONTROL MAIN SWITCH IND
DASH LIGHTS BRIGHTNESS CONTROLLER
DRIVE CIRCUIT
DRIVE CIRCUIT SPEEDO- METER
ENGINE COOLANT TEMPERATURE GAUGE
FAIL SAFE CIRCUIT
FAST CONTROLLER AREA NETWORK TRANSCEIVER
FOG LIGHT IND
FUEL GAUGE
GAUGE CONTROL MODULE
GRN WIRE
GRN/RED WIRE
GRY WIRE
HIGH BEAM IND
IMMOBILIZER SYSTEM IND
INFO SWITCH
J/C
LEFT TURN SIGNAL IND
LIGHTS ON IND
LOW FUEL IND
LOW OIL PRESSIRE IND
LT BLU WIRE
LT GRN WIRE
MIL IND
MULTI INFORMATION DISPLAY (MID) UNIT
ORG/ WIRE
PNK WIRE
PNK/BLU WIRE
POWER SUPPLY CIRCUIT/CONTROLLER AREA NETWORK CONTROLLER
RED WIRE
RED/BLU WIRE
RIGHT TURN SIGNAL IND
SEAT BELT REMINDER IND
SECURITY IND
SECURITY INDICATOR BLINK CIRCUIT
SELECT/ RESET SWITCH
SHIFT IND
SHIFT IND BRIGHT CTRL, DIMMING CKT
SIDE AIR BAG CUT-OFF IND
SRS IND
SYSTEM MESSAGE IND
TACHO- METER
VSA ACTIVATION IND
VSA IND
WARNING DRIVE CIRCUIT
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Instrument cluster circuit (1 of 2) -> SIDE AIR BAG CUT-OFF IND
