Acura TSX I (2003-2008) radio remote switch Wiring diagrams

This page contains all the electrical diagrams for the component. radio remote switch, in which he is found in the car Acura TSX I (2003-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

radio remote switch wiring diagram (1 of 4)

AUDIO HVAC- SUB DISPLAY UNIT (NAVIGATION) CLOCK (EXCEPT NAVIGATION) AUDIO-HVAC DISPLAY PANEL BLK WIRE BLU WIRE BRN WIRE CABLE REEL CEILING LIGHT CHANNEL DOWN SWITCH CHANNEL UP SWITCH CLOCK DATA DOOR DRIVER'S DOOR SPEAKER FRONT PASSENGER'S DOOR SPEAKER GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE GRY/RED WIRE LC BL (-) LCD BL (+) LCD BL (-) SIG SH CE DATA CLOCK RESET LT GRN WIRE MODE SWITCH OFF ORG/ WIRE PPL RADIO REMOTE SWITCH RED WIRE RED/BLK WIRE RESET+ SIG GND SIG SH STEERING WHEEL) UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) VIDEO MONITOR CONSOLE VOICE CONTROL SWITCH VOLUME DOWN SWITCH VOLUME UP SWITCH W/ NAVI W/ NAVIGATION WHT WIRE WHT/BLU WIRE YEL WIRE

Go to component -> Dvd player circuit, with cassette or mp3 player (3 of 3) -> RADIO REMOTE SWITCH

radio remote switch wiring diagram (2 of 4)

Go to component -> Dvd player circuit, without cassette or mp3 player (3 of 3) -> RADIO REMOTE SWITCH

radio remote switch wiring diagram (3 of 4)

AUDIO HVAC- SUB DISPLAY UNIT (NAVIGATION) CLOCK (EXCEPT NAVIGATION) AUDIO-HVAC DISPLAY PANEL BLK WIRE BLU WIRE BRN WIRE CABLE REEL CHANNEL DOWN SWITCH CHANNEL UP SWITCH CLOCK DATA DRIVER'S DOOR SPEAKER FRONT PASSENGER'S DOOR SPEAKER GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE GRY/RED WIRE LC BL (-) LT GRN WIRE MODE SWITCH ORG/ WIRE PPL RADIO REMOTE SWITCH RED WIRE RED/BLK WIRE RESET CLOCK DATA CE SIG SH LCD BL- LCD BL+ PPL RESET+ SIG GND SIG SH STEERING WHEEL) UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) VOICE CONTROL SWITCH VOLUME DOWN SWITCH VOLUME UP SWITCH W/ NAVI W/O NAVI W/ NAVIGATION W/O NAVI W/ NAVI YEL WIRE

Go to component -> Radio circuit, with cassette or mp3 player (3 of 3) -> RADIO REMOTE SWITCH
