Acura TSX I (2003-2008) power window master switch driving position memory switch Wiring diagram
This page shows the only wiring diagram for the component.power window master switch driving position memory switch, which is found in the car Acura TSX I (2003-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power window master switch driving position memory switch (1 of 1)
A/C COMPRESSOR CLUTCH RELAY
A/C CONDENSER FAN RELAY
AUDIO UNIT
AUDIO-HVAC DISPLAY PANEL
BLK WIRE
BLOWER MOTOR RELAY
BLU WIRE
CEILING LIGHT AMBIENT LIGHT
COMBINATION SWITCH CONTROL UNIT
CONTROL BLOCK
CORNER OF ENGINE COMPT, FORWARD OF STRUT TOWER)
DRIVER'S DOOR COURTESY LIGHT
DRIVER'S VANITY MIRROR LIGHT
FROM ELD UNIT (DIAGRAM 1 OF 4)
FROM IGNITION SWITCH (DIAGRAM 2 OF 4)
FRONT PASSENGER'S DOOR COURTESY LIGHT
FRONT PASSENGER'S VANITY MIRROR LIGHT
FUSE 15
FUSE 2
FUSE 30
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 8
GAUGE CONTROL MODULE
HANDS FREELINK CONTROL UNIT
HIGH BEAM HEADLIGHT RELAY
IMMOBILIZER CONTROL UNIT- RECEIVER
JUNCTION CONNECTOR
LOW BEAM HEADLIGHT RELAY
MICU
NAVIGATION DISPLAY UNIT (IF EQUIPPED)
NAVIGATION UNIT (IF EQUIPPED)
POWER MIRROR SWITCH
POWER SEAT CONTROL UNIT
POWER WINDOW MASTER SWITCH DRIVING POSITION MEMORY SWITCH
RADIATOR FAN RELAY
REAR WINDOW DEFOGGER RELAY
RECIRCULATION CONTROL MOTOR
RED WIRE
RELAY CONTROL MODULE
SEAT HEATER RELAY
STEREO AMPLIFIER INDIVIDUAL MAP LIGHTS
TAILLIGHT RELAY
TO ACCESSORY POWER SOCKET RELAY (DIAGRAM 4 OF 4)
TRUNK LIGHT
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
UNDER-HOOD FUSE/RELAY BOX (ON LEFT REAR
WHT WIRE
WIPER/WASHER SWITCH
YEL WIRE
Go to component -> Power distribution circuit (3 of 4) -> POWER WINDOW MASTER SWITCH DRIVING POSITION MEMORY SWITCH
