Acura TSX I (2003-2008) fuse 26 Wiring diagram
This page shows the only wiring diagram for the component.fuse 26, which is found in the car Acura TSX I (2003-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 26 (1 of 1)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
DOOR
DOOR MULTIPLEX CONTROL UNIT
DOWN
DRIVER'S POWER WINDOW MOTOR (IN MIDDLE OF DRIVER'S
DRIVER'S SWITCH 0) OFF 1) UP 2) DOWN 3) AUTO DOWN 4) AUTO UP
FRONT PASSENGER SWITCH
FUSE 21
FUSE 24
FUSE 25
FUSE 26
FUSE 27
FUSE 7
GRN/BLK WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LEFT REAR SWITCH
MAIN SWITCH
MICU
OFF
ORG/ WIRE
PLSA
PLSB
POWER WINDOW MASTER SWITCH
POWER WINDOW RELAY
PULSER
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT REAR SWITCH
SVCC
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
UP (+)
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Power windows circuit (1 of 2) -> FUSE 26
