Acura TSX I (2003-2008) communication line pedal pos sw ignition input battery input Wiring diagram

ANTI-THEFT SYSTEM ANTI-THEFT SYSTEM DOOR LOCKS SYSTEM ANTI-THEFT SYSTEM POWER TOPS SYSTEM ATP-R BACK LT K LINE IG KEY LT BLK WIRE BLU WIRE BLU/RED WIRE BOX (BEHIND LEFT KICK PANEL) BRN WIRE BRN/RED WIRE CLIMATE CONTROL UNIT WIPER/ WASHER SWITCH POWER WINDOW MASTER SWITCH COMM LINE COMM LINE COMM LINE COMM LINE COMMUNICATION LINE PEDAL POS SW IGNITION INPUT BATTERY INPUT DLC (LOWER LEFT OF DASH, ABOVE THE KICK PANEL) DOOR LOCKS SYSTEM EXTERIOR LIGHTS SYSTEM SHIFT INTERLOCK SYSTEM EXTERIOR LIGHTS SYSTEMS FR PASS COURT LT RADIO SW SIL RD UNLOCK SIL RA UNLOCK FUSE 21 FUSE 3 FUSE 8 FUSE 7 FUSE 32 FUSE 7 FUSE 13 GAUGE CONTROL MODULE GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GROUND P PIN SW HAZ RLY HOT AT ALL TIMES HOT IN ON OR ACC HOT IN ON OR START IGNITION KEY LIGHT IGNITION KEY SWITCH IGNITION KEY SWITCH/ KEY LIGHT INTERIOR LIGHTS SYSTEM SOUND SYSTEMS JUNCTION CONNECTOR KEY SOL ATP-R LT BLU WIRE LT GRN WIRE LT GRN/RED WIRE MICU MULTIPLEX CONTROL INSPECTION CONNECTOR NOT USED NOT USED PNK WIRE RED WIRE RELAY CONTROL MODULE REM AS UNLOCK SHIFT INTERLOCK SYSTEM TRANSMISSION SYSTEMS SIL AS UNLOCK TRANSMISSION SYSTEMS TRUNK SWITCH REM AS LOCK TRUNK UNLOCK SUNROOF RLY IG KEY SW TRUNK/TAILGATE/ FUEL DOORS SYSTEM TURN SIGNAL/ HAZARD RELAY UNDER-DASH FUSE/RELAY UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) UNDER-HOOD FUSE/RELAY BOX WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE
