Acura TSX I (2003-2008) cancel switch resume switch Wiring diagram
This page shows the only wiring diagram for the component.cancel switch resume switch, which is found in the car Acura TSX I (2003-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cancel switch resume switch (1 of 1)
5 6 (CANADA)
AUDIO UNIT
AUDIO-HVAC DISPLAY PANEL
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH (ON BRAKE FLUID RESERVOIR)
BRN WIRE
CABLE REEL
CAN H CAN L SIGNAL OUTPUT
CANCEL SWITCH RESUME SWITCH
CONTROL BLOCK
CORNER OF ENGINE COMPT, FORWARD OF STRUT TOWER)
CRUISE CONTROL COMBINATION SWITCH
DRIVER'S DOOR SWITCH
ECM/PCM (UNDER MIDDLE
FRONT PASS- ENGER'S DOOR SWITCH
FUEL GAUGE SENDING UNIT
FUEL TANK UNIT (IN TOP OF FUEL TANK, AT LEFT FRONT OF TRUNK)
FUSE 21
FUSE 7
GRN WIRE
GRN/RED WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IMMOBILIZER CONTROL UNIT -RECEIVER (IN STEERING COLUMN COVER)
INFO SWITCH
J/C
LEFT REAR DOOR SWITCH
LT BLU WIRE
LT GRN WIRE
MAIN SWITCH
MICU
OF DASH)
OIL PRESSURE SWITCH (AT RIGHT FRONT OF ENGINE)
OPDS UNIT (IN FRONT PASSENGER'S SEAT BACK)
ORG/ WIRE
ORG/BLU WIRE
PARKING BRAKE SWITCH (MOUNTED UNDER PARKING BRAKE LEVER)
PNK (OR WIRE
PNK (UNDER LEFT SIDE OF DASH) WIRE
PNK 15 16 WIRE
PNK WIRE
PNK/BLU WIRE
POWER SEATS SYSTEM (M/T)
RED WIRE
RELAY CONTROL MODULE
RIGHT REAR DOOR SWITCH
SELECT/ RESET SWITCH
SELECT/RESET/INFORMATION SWITCH
SET SWITCH
SRS UNIT (UNDER MIDDLE OF DASH)
STEERING WHEEL)
TRUNK LATCH SWITCH (AT MIDDLE REAR OF TRUNK LID)
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
UNDER-HOOD FUSE/RELAY BOX (ON LEFT REAR
VSA OFF SWITCH
W/ NAVI W/O NAVI
W/O NAVI W/ NAVI
WASHER FLUID LEVEL SWITCH (CANADA)
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Instrument cluster circuit (2 of 2) -> CANCEL SWITCH RESUME SWITCH
