Acura TSX I (2003-2008) brake pedal position switch ignition key switch/ key light hazard warning switch Wiring diagram
This page shows the only wiring diagram for the component.brake pedal position switch ignition key switch/ key light hazard warning switch, which is found in the car Acura TSX I (2003-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram brake pedal position switch ignition key switch/ key light hazard warning switch (1 of 1)
A/C COMPRESSOR CLUTCH RELAY
A/C CONDENSER FAN RELAY
A/F SENSOR RELAY MICU
ALTERNATOR
BATTERY
BLK WIRE
BLOWER MOTOR RELAY
BLU WIRE
BOX (ON LEFT REAR CORNER OF ENGINE COMPT, FORWARD OF STRUT TOWER)
BRAKE PEDAL POSITION SWITCH IGNITION KEY SWITCH/ KEY LIGHT HAZARD WARNING SWITCH
DLC
ELECTRICAL LOAD DETECTOR (ELD) UNIT
FOG LIGHT RELAY
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FUSE 10
FUSE 11 FUSE 18
FUSE 12 (NOT USED)
FUSE 12 FUSE 2 (NOT USED)
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 17
FUSE 19
FUSE 20
FUSE 21
FUSE 4 FUSE 1 FUSE 3
FUSE 8
FUSE 9
GRN WIRE
HORN RELAY RELAY CONTROL MODULE
IGNITION COIL RELAY
MULTI- FUSE 22
ORG/ WIRE
PGM-FI MAIN RELAY 1
POWER SEAT CONTROL UNIT
RADIATOR FAN RELAY
REAR WINDOW DEFOGGER RELAY
RED WIRE
RED/BLU WIRE
SEAT HEATER RELAY
STARTER
STARTER SOLENOID
THROTTLE ACTUATOR CONTROL MODULE RELAY DRL RELAY (CANADA)
TO FUSE 15 (DIAGRAM 3 OF 4)
TO MULTI-FUSE 23 (DIAGRAM 2 OF 4)
TURN SIGNAL/ HAZARD RELAY
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
UNDER-HOOD FUSE/RELAY
VSA MODULATOR CONTROL UNIT
WHT (OR BLK/YEL) WIRE
WHT WIRE
Go to component -> Power distribution circuit (1 of 4) -> BRAKE PEDAL POSITION SWITCH IGNITION KEY SWITCH/ KEY LIGHT HAZARD WARNING SWITCH
