Radio circuit, 13 speakers for Acura TLX II (2020-2024)

12 VOLT BATTERY 12 VOLT BATTERY SENSOR BLK WIRE BLU WIRE BRN WIRE CENTER DISPLAY UNIT CIRCUIT COMPUTER DATA EXTERIOR FUSE 32 FUSE 36 FUSE 4 FUSE 4-2 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ HOT W/ ACC RELAY ENERGIZED INFOTAINMENT CONTROL UNIT JUNCTION BOX B LIGHTS SYSTEM LINES SYSTEM LT BLU WIRE LT GRN WIRE NAVIGATION NAVIGATION SYSTEM NCA WIRE PNK WIRE PPL REAR CAMERA RED WIRE RESTRAINTS SYSTEM SEATS SYSTEM SUPPLEMENTAL SYSTEM TAN WIRE TELEMATICS CONTROL UNIT (CENTER OF DASH) UNDER-DASH FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

BLK WIRE BLU WIRE BRN WIRE DC-DC CONVERTER DC-DC CONVERTER ACC RELAY FUSE 46 FUSE 47 FUSE 48 FUSE/RELAY HOLDER C GRN WIRE GRY WIRE HOT AT ALL TIMES INTERIOR LIGHTS JUNCTION BOX B LT BLU WIRE LT GRN WIRE NCA WIRE PNK WIRE PPL RED WIRE SYSTEM TAN WIRE TEL ANTENNA (PRIMARY) TEL ANTENNA (SECONDARY) USB CHARGER UNIT USB PORT B (CHARGE ONLY) VOLUME, SEEK SWITCH WHT WIRE YEL WIRE

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA COMPUTER DATA LINES SYSTEM FRONT HFL-ANC/ACTIVE SOUND CONTROL MICROPHONE GRN WIRE GRY WIRE JUNCTION BOX C (LEFT CENTER OF DASH) LINES SYSTEM LT BLU WIRE LT GRN WIRE MIDDLE ANC/ ACTIVE SOUND CONTROL MICROPHONE PNK WIRE POWER DISTRIBUTION MODULE (LEFT END OF DASH) PPL REAR ANC/ ACTIVE SOUND CONTROL MICROPHONE RED WIRE ROOF ANTENNA (CENTER REAR VEHICLE ROOF) ROOF CONSOLE MODULE TAN WIRE TOUCHPAD UNIT WHT WIRE YEL WIRE

ACC COMBINATION SWITCH APPS SWITCH AUDIO REMOTE- HFL SWITCH BACK SWITCH BLK WIRE BLU WIRE BRN WIRE CABLE REEL FWD SWITCH GRN WIRE GRY WIRE LIN I/F LT GRN WIRE MCU PNK WIRE POWER SWITCH PPL PUSH SWITCH RED WIRE REGULATOR REW SWITCH TALK SWITCH TAN WIRE TUNER UNIT (REAR PACKAGE SHELF) VOL+ SWITCH WHT WIRE YEL WIRE

ASSIST SWITCH B-CAN B-CAN H B-CAN L BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 1-3 FUSE 17 GAUGE CONTROL MODULE GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT SUBWOOFER LINK SWITCH LT GRN WIRE PNK WIRE PPL RED WIRE STEREO AMPLIFIER (CENTER CONSOLE) TAN WIRE TRANSCEIVER/ UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA DRIVER'S DOOR SPEAKER (17 CM) DRIVER'S DOOR SPEAKER (9 CM) FRONT CENTER TWEETER FRONT PASSENGER'S DOOR SPEAKER (17 CM) FRONT PASSENGER'S DOOR SPEAKER (9 CM) GRN WIRE GRY WIRE INFOTAINMENT CONTROL UNIT LEFT FRONT ROOF SPEAKER LEFT SATELLITE SPEAKER LEFT TWEETER LINES SYSTEM LT BLU WIRE LT GRN WIRE PNK WIRE PPL RED WIRE RIGHT FRONT ROOF SPEAKER RIGHT SATELLITE SPEAKER RIGHT SUBWOOFER RIGHT TWEETER STEREO AMPLIFIER (CENTER CONSOLE) TAN WIRE WHT WIRE YEL WIRE
