Radio circuit, 10 speakers for Acura TLX II (2020-2024)

BLK WIRE BLU WIRE BRN WIRE CENTER DISPLAY UNIT COMPUTER DATA LINES SYSTEM FUSE 32 FUSE 36 FUSE 4 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ HOT W/ ACC RELAY ENERGIZED INFOTAINMENT CONTROL UNIT JUNCTION BOX B LT BLU WIRE NAVIGATION SYSTEM NCA WIRE PNK WIRE PPL REAR CAMERA CIRCUIT RED WIRE TAN WIRE TELEMATICS CONTROL UNIT (CENTER OF DASH) UNDER-DASH FUSE/RELAY BOX USB CHARGER UNIT USB PORT B (CHARGE ONLY) WHT WIRE YEL WIRE

AUDIO REMOTE- HFL SWITCH BACK BLK WIRE BLU WIRE CABLE REEL DC-DC CONVERTER FUSE 4-2 FUSE 47 FUSE 48 FUSE/ RELAY HOLDER C GRN WIRE GRY WIRE HEATED STEERING WHEEL IND HEATED STEERING WHEEL SWITCH HOT AT ALL TIMES JUNCTION BOX B (LEFT CENTER OF DASH) L JOG LIN I/F LT BLU WIRE MCU NCA WIRE PNK WIRE POWER PPL PUSH RED WIRE REGULATOR REW SEATS SYSTEM TALK APPS TAN WIRE UNDER-HOOD FUSE/RELAY BOX VOL (-) WHT WIRE YEL WIRE

ACC COMBINATION SWITCH ANC/ACTIVE SOUND CONTROL UNIT BLK WIRE BLU WIRE BRN WIRE COMPUTER COMPUTER DATA LINES SYSTEM DATA LINES FRONT HFL-ANC/ACTIVE SOUND CONTROL MICROPHONE GRN WIRE GRY WIRE INTERIOR LIGHTS JUNCTION BOX C LT BLU WIRE LT GRN WIRE MIDDLE ANC/ ACTIVE SOUND CONTROL MICROPHONE PNK WIRE POWER DISTRIBUTION MODULE (LEFT END OF DASH) PPL REAR ANC/ ACTIVE SOUND CONTROL MICROPHONE RED WIRE ROOF ANTENNA (CENTER REAR VEHICLE ROOF) ROOF CONSOLE MODULE SYSTEM TAN WIRE TOUCHPAD UNIT VOLUME, SEEK SWITCH WHT WIRE YEL WIRE

12 VOLT BATTERY 12 VOLT BATTERY SENSOR B-CAN B-CAN H B-CAN L BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM FUSE 1-3 GAUGE CONTROL MODULE GRN WIRE GRY WIRE HEATED STEERING WHEEL CONTROL UNIT HOT AT ALL TIMES LEFT SUBWOOFER LT GRN WIRE PNK WIRE PPL RED WIRE RIGHT SUBWOOFER STEREO AMPLIFIER (CENTER CONSOLE) TAN WIRE TRANSCEIVER/ TUNER UNIT (REAR PACKAGE SHELF) UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER'S DOOR SPEAKER (17 CM) DRIVER'S DOOR SPEAKER (9 CM) FRONT PASSENGER'S DOOR SPEAKER (17 CM) FRONT PASSENGER'S DOOR SPEAKER (9 CM) GRN WIRE GRY WIRE INFOTAINMENT CONTROL UNIT LEFT SATELLITE SPEAKER LEFT TWEETER LT BLU WIRE LT GRN WIRE PNK WIRE PPL RED WIRE RIGHT SATELLITE SPEAKER RIGHT TWEETER STEREO AMPLIFIER (CENTER CONSOLE) TAN WIRE WHT WIRE YEL WIRE
