Blind spot monitoring circuit for Acura TLX II (2020-2024)
Blind spot monitoring circuit
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLK WIRE
COMPUTER DATA LINES SYSTEM
FUSE 49
FUSE/RELAY HOLDER C
GAUGE CONTROL MODULE
HOT W/ DC-DC
LEFT BSI ALERT INDICATOR
LEFT SIDE BSI RADAR UNIT
LT BLU WIRE
PNK WIRE
RELAY 2 ENERGIZED
RIGHT BSI ALERT INDICATOR
RIGHT SIDE BSI RADAR UNIT
TAN WIRE
THERMAL JOINT 7
THERMAL JOINT 8
WHT WIRE
YEL WIRE
