Instrument cluster circuit for Acura TLX II (2020-2024)

12 VOLT CHARGING SYSTEM IND ABS IND. ANTI-LOCK BRAKES SYSTEM AUTO HIGH BEAM IND (GREEN) AWD SYSTEM IND B-CAN H B-CAN L B-CAN TRANSCEIVER BLK WIRE BLU WIRE BRAKE SYSTEM IND (AMBER) BRAKE SYSTEM IND (RED) WIRE BRN WIRE BUZZER COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM EPS IND F-CAN F-CAN H F-CAN L FRONT FOG LIGHT IND FUEL/ TEMPERATURE METER, MULTI- INFORMATION DISPLAY FUSE 17 FUSE 47 FUSE/RELAY HOLDER C GAUGE CONTROL MODULE GRN WIRE GRY WIRE HEAD-UP DISPLAY CIRCUIT HIGH BEAM IND HOT AT ALL TIMES IDLE STOP OFF/AUTOMATIC BRAKE HOLD SWITCH ILLUM INTEGRATED DYNAMICS SYSTEM SWITCH LEFT TURN SIGNAL IND LIGHTS ON IND LIN TRANSCEIVER LT BLU WIRE LT GRN WIRE MALFUNCTION IND LAMP (MIL) MOST MULTI VISOR SWITCH NCA WIRE PNK WIRE PPL RED WIRE RIGHT TURN SIGNAL IND SAFETY SUPPORT SEAT BELT REMINDER IND SECURITY IND SOUND SYSTEMS SRS IND TAN WIRE TFT TPMS IND TRANSCEIVER/ UNDER-HOOD FUSE/RELAY BOX VSA IND VSA OFF VSA OFF IND WHT WIRE WIPER/WASHER SYSTEM YEL WIRE

2.0L TURBO 3.0L TURBO BLK WIRE BLU WIRE BODY CONTROL MODULE BRAKE FLUID LEVEL SWITCH BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER'S DOOR LATCH DRIVER'S DOOR SWITCH ELECTRIC SERVO BRAKE CONTROL UNIT/PEDAL FEEL SIMULATOR ENGINE OIL PRESSURE SENSOR ENGINE OIL PRESSURE SWITCH FRONT PASSENGER'S DOOR LATCH FRONT PASSENGER'S DOOR SWITCH FUEL TANK UNIT FUSE 36 GRN WIRE GRY WIRE LEFT REAR DOOR LATCH LEFT REAR DOOR SWITCH LOWER RIGHT FRONT OF ENGINE) LT GRN WIRE PCM PNK WIRE PPL RED WIRE RELAY ENERGIZED RIGHT REAR DOOR LATCH RIGHT REAR DOOR SWITCH SECONDARY FUEL GAUGE SENDING UNIT TAN WIRE UNDER-DASH FUSE/RELAY BOX WHT WIRE
