Car Wiring Diagrams for Cruise control circuit for Acura TLX II (2020-2024)

2.0L TURBO 3.0L TURBO APP SENSOR A APP SENSOR A/B (LEFT CENTER OF DASH) APP SENSOR B BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COUNTERSHAFT SPEED SENSOR ELECTRONIC THROTTLE CONTROL SYSTEM (ETCS) CONTROL RELAY ENGINE CONTROLS SYSTEM FUSE 15 FUSE 16 FUSE 17 FUSE 4-2 FUSE 7 FUSE/RELAY HOLDER B GRN WIRE GRY WIRE HOT AT ALL TIMES JOINT 2 LT BLU WIRE LT GRN WIRE MILLIMETER WAVE RADAR MULTIPURPOSE CAMERA UNIT PCM PNK WIRE PPL REAR VIEW MIRROR) RED WIRE THROTTLE ACTUATOR THROTTLE BODY (INTAKE MANIFOLD OPENING) THROTTLE OPEN SENSOR TRANSMISSION ASSEMBLY TRANSMISSION CONTROL MODULE (TCM) UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

ACC COMBINATION SWITCH ACC SWITCH AUDIO REMOTE- HFL SWITCH BLK WIRE BLU WIRE CABLE REEL CANCEL SWITCH COMPUTER DATA LINES SYSTEM DC-DC CONVERTER DISTANCE SWITCH F-CAN F-CAN H F-CAN L FUSE 48 FUSE 49 FUSE/RELAY HOLDER C GAUGE CONTROL MODULE GRN WIRE HOT W/ DC-DC LEFT LKAS SWITCH LT BLU WIRE LT GRN WIRE MCU PNK WIRE PPL PUSH RED WIRE REGULATOR RELAY 2 ENERGIZED RES/+ SWITCH RIGHT SET SWITCH TAN WIRE TRANSCEIVER/ WHT WIRE YEL WIRE

BLU WIRE BRAKE PEDAL POSITION SWITCH BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 35 GRN WIRE GRY WIRE HOT W/ LEFT FRONT WHEEL SPEED SENSOR LEFT REAR WHEEL SPEED SENSOR LT BLU WIRE LT GRN WIRE NCA WIRE PNK WIRE PPL RIGHT FRONT WHEEL SPEED SENSOR RIGHT REAR WHEEL SPEED SENSOR UNDER-DASH FUSE/RELAY BOX VSA MODULATOR CONTROL UNIT W/ ADAPTIVE DAMPER SYSTEM W/O ADAPTIVE DAMPER SYSTEM WHT WIRE YEL WIRE
