Acura TLX II (2020-2024) rocker arm oil control valve Wiring diagrams
This page contains all the electrical diagrams for the component. rocker arm oil control valve, in which he is found in the car Acura TLX II (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rocker arm oil control valve (1 of 2)
2.0L TURBO
3.0L TURBO
A/F SENSOR (SENSOR 1) SHIELD
BLK WIRE
BRN WIRE
HIGH PRESSURE FUEL PUMP SHIELD
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION COIL 5
IGNITION COIL 6
INJECTOR 1 SHIELD
INJECTOR 2 SHIELD
INJECTOR 3 SHIELD
INJECTOR 4 SHIELD
KNOCK SENSOR 1 (BANK 1) SHIELD
KNOCK SENSOR 2 (BANK 2) SHIELD
KNOCK SENSOR SHIELD
PCM
ROCKER ARM OIL CONTROL VALVE
THERMAL JOINT 4
VTC OIL CONTROL SOLENOID VALVE A (BANK 1)
VTC OIL CONTROL SOLENOID VALVE A (BANK 2)
VTC OIL CONTROL SOLENOID VALVE B (BANK 1)
VTC OIL CONTROL SOLENOID VALVE B (BANK 2)
Go to component -> Ground distribution circuit (6 of 6) -> ROCKER ARM OIL CONTROL VALVE
Wiring diagram rocker arm oil control valve (2 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
CMP SENSOR A (BANK 1)
COMPUTER DATA LINES SYSTEM
F-CAN
F-CAN H
F-CAN L
FRONT A/F SENSOR (BANK 2, SENSOR 1)
FUEL RAIL PRESSURE SENSOR
FUSE 17
GAUGE CONTROL MODULE
GRN WIRE
HOT AT ALL TIMES
ICM
IGNITION COIL 5 (TOP OF ENGINE)
IGNITION COIL 6 (TOP OF ENGINE)
LT BLU WIRE
LT GRN WIRE
MALFUNCTION INDICATOR LAMP (MIL)
PNK WIRE
PPL
RED WIRE
ROCKER ARM OIL CONTROL VALVE
SPARK PLUG
TAN WIRE
TRANSCEIVER/
TURBOCHARGER WASTEGATE CONTROL ACTUATOR
TURBOCHARGER WASTEGATE CONTROL ACTUATOR POSITION SENSOR
UNDER-HOOD FUSE/RELAY BOX
VTC OIL CONTROL SOLENOID VALVE A (BANK 2)
YEL WIRE
Go to component -> Wiring diagram engine performance 3.0l turbo (6 of 7) -> ROCKER ARM OIL CONTROL VALVE
