Acura TLX II (2020-2024) right rear acceleration sensor Wiring diagram
This page shows the only wiring diagram for the component.right rear acceleration sensor, which is found in the car Acura TLX II (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear acceleration sensor (1 of 1)
ADAPTIVE DAMPER CONTROL UNIT
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 37
FUSE 7
FUSE/RELAY HOLDER A
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
LEFT FRONT DAMPER ACTUATOR
LEFT FRONT SUSPENSION STROKE SENSOR
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
RED WIRE
RIGHT FRONT DAMPER ACTUATOR
RIGHT FRONT SUSPENSION STROKE SENSOR
RIGHT REAR ACCELERATION SENSOR
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Adaptive damping circuit (1 of 2) -> RIGHT REAR ACCELERATION SENSOR
