Acura TLX II (2020-2024) mode select switch Wiring diagrams
This page contains all the electrical diagrams for the component. mode select switch, in which he is found in the car Acura TLX II (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram mode select switch (1 of 2)
- LUMBAR SUPPORT ADJUSTMENT SWITCH
BACKWARD
BLK WIRE
BLU WIRE
BOLSTER/LUMBAR/ THIGH SUPPORT ADJUSTMENT SWITCH
BRN WIRE
DOWN
DRIVER'S POWER SEAT ADJUSTMENT SWITCH
DRIVER'S POWER SEAT CONTROL UNIT
FORWARD/
FUSE 17
FUSE 34
FUSE 49
FUSE 8
FUSE/RELAY HOLDER B
FUSE/RELAY HOLDER C
GRN WIRE
GRY WIRE
HEIGHT SWITCH
HOT AT ALL TIMES
HOT W/ DC-DC
LT BLU WIRE
LT GRN WIRE
MODE SELECT SWITCH
PNK WIRE
PPL
RECLINE SWITCH
RED WIRE
RELAY 2 ENERGIZED
SLIDE SWITCH
TAN WIRE
TILT SWITCH
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Memory seat circuit (3 of 3) -> MODE SELECT SWITCH
Wiring diagram mode select switch (2 of 2)
BACKWARD
BLK WIRE
BLU WIRE
BOLSTER/ LUMBAR/ THIGH SUPPORT ADJUSTMENT SWITCH
DOWN
FORWARD/
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FRONT PASSENGER'S SEAT LEFT BOLSTER MOTOR
FRONT PASSENGER'S SEAT POWER THIGH SUPPORT MOTOR
FRONT PASSENGER'S SEAT RIGHT BOLSTER MOTOR
GRN WIRE
GRY WIRE
HEIGHT SWITCH
LT BLU WIRE
LT GRN WIRE
MODE SELECT SWITCH
PNK WIRE
POSITION SENSOR
PPL
RECLINE SWITCH
RED WIRE
SLIDE SWITCH
TAN WIRE
TILT SWITCH
WHT WIRE
YEL WIRE
Go to component -> Passenger power seat circuit, 16-way (2 of 3) -> MODE SELECT SWITCH
