Acura TLX II (2020-2024) - lumbar support adjustment switch Wiring diagrams
This page contains all the electrical diagrams for the component. - lumbar support adjustment switch, in which he is found in the car Acura TLX II (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram - lumbar support adjustment switch (1 of 2)
- LUMBAR SUPPORT ADJUSTMENT SWITCH
BACKWARD
BLK WIRE
BLU WIRE
BOLSTER/LUMBAR/ THIGH SUPPORT ADJUSTMENT SWITCH
BRN WIRE
DOWN
DRIVER'S POWER SEAT ADJUSTMENT SWITCH
DRIVER'S POWER SEAT CONTROL UNIT
FORWARD/
FUSE 17
FUSE 34
FUSE 49
FUSE 8
FUSE/RELAY HOLDER B
FUSE/RELAY HOLDER C
GRN WIRE
GRY WIRE
HEIGHT SWITCH
HOT AT ALL TIMES
HOT W/ DC-DC
LT BLU WIRE
LT GRN WIRE
MODE SELECT SWITCH
PNK WIRE
PPL
RECLINE SWITCH
RED WIRE
RELAY 2 ENERGIZED
SLIDE SWITCH
TAN WIRE
TILT SWITCH
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Memory seat circuit (3 of 3) -> - LUMBAR SUPPORT ADJUSTMENT SWITCH
Wiring diagram - lumbar support adjustment switch (2 of 2)
- LUMBAR SUPPORT ADJUSTMENT SWITCH
BACKWARD
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
DOWN
DRIVER'S POWER SEAT CONTROL UNIT
FORWARD/
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FRONT PASSENGER'S SEAT POWER LUMBAR SUPPORT MOTOR A
FRONT PASSENGER'S SEAT POWER LUMBAR SUPPORT MOTOR B
FRONT PASSENGER'S SEAT TILT MOTOR
GRY WIRE
HEIGHT SWITCH
LT BLU WIRE
LT GRN WIRE
MODE SWITCH
PNK WIRE
PPL
RECLINE SWITCH
RED WIRE
SLIDE SWITCH
TILT SWITCH
TRANSMISSION ASSEMBLY
TRANSMISSION CONTROL MODULE (TCM)
WHT WIRE
YEL WIRE
Go to component -> Passenger power seat circuit, 12-way (2 of 2) -> - LUMBAR SUPPORT ADJUSTMENT SWITCH
