Acura TLX II (2020-2024) left front driver's seat belt buckle switch Wiring diagram
This page shows the only wiring diagram for the component.left front driver's seat belt buckle switch, which is found in the car Acura TLX II (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front driver's seat belt buckle switch (1 of 1)
BLK WIRE
BRN WIRE
CENTER DISPLAY UNIT
CLIMATE CONTROL SWITCH
DRIVER'S BACK SEAT BLOWER MOTOR
DRIVER'S BACK SEAT HEATER
DRIVER'S POWER SEAT CONTROL UNIT
DRIVER'S SEAT CUSHION BLOWER MOTOR
DRIVER'S SEAT CUSHION HEATER
DRIVER'S SEAT HEIGHT MOTOR
DRIVER'S SEAT LEFT BOLSTER MOTOR
DRIVER'S SEAT POSITION SENSOR
DRIVER'S SEAT POWER LUMBAR SUPPORT MOTOR A
DRIVER'S SEAT POWER LUMBAR SUPPORT MOTOR B
DRIVER'S SEAT POWER THIGH SUPPORT MOTOR
DRIVER'S SEAT RECLINE MOTOR
DRIVER'S SEAT RIGHT BOLSTER MOTOR
DRIVER'S SEAT SLIDE MOTOR
DRIVER'S SEAT TILT MOTOR
FRONT ACCESSORY POWER SOCKET
FRONT SEAT HEATER/VENTILATED SEAT CONTROL UNIT
GLOVE BOX LIGHT
GRY WIRE
HIGH MOUNT BRAKE LIGHT
IDLE STOP OFF/AUTOMATIC BRAKE HOLD SWITCH
INFOTAINMENT CONTROL UNIT
INTEGRATED DYNAMICS SYSTEM SWITCH
LEFT FRONT DRIVER'S SEAT BELT BUCKLE SWITCH
REAR DIFFERENTIAL PUMP MOTOR
RIGHT REAR DOOR INNER HANDLE LIGHT
RIGHT REAR DOOR LATCH
RIGHT REAR DOOR OUTER HANDLE
RIGHT REAR POWER WINDOW SWITCH
RIGHT REAR SEAT BACK HEATER
RIGHT REAR SEAT CUSHION HEATER
SECONDARY FUEL GAUGE SENDING UNIT SHIELD
TELEMATICS CONTROL UNIT
TRUNK LID OPENER MAIN SWITCH
USB CHARGER UNIT
W/ KEYLESS ACCESS
Go to component -> Ground distribution circuit (4 of 6) -> LEFT FRONT DRIVER'S SEAT BELT BUCKLE SWITCH
