Acura TLX II (2020-2024) heated windshield wiper area Wiring diagrams
This page contains all the electrical diagrams for the component. heated windshield wiper area, in which he is found in the car Acura TLX II (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram heated windshield wiper area (1 of 2)
ADAPTIVE DAMPER CONTROL UNIT
BLK WIRE
BRAKE FLUID LEVEL SWITCH
BRAKE PEDAL STROKE SENSOR SHIELD
CAN GATEWAY
CENTER CONSOLE ACCESSORY POWER SOCKET
CLIMATE CONTROL UNIT
DC-DC CONVERTER
DC-DC CONVERTER ACC RELAY
DRIVER'S FOOTWELL LIGHT
DRIVER'S INSTRUMENT PANEL AMBIENT LIGHT
EPS CONTROL UNIT
FRONT PASSENGER'S DOOR AMBIENT LIGHT
FRONT PASSENGER'S DOOR INNER HANDLE LIGHT
FRONT PASSENGER'S DOOR LATCH
FRONT PASSENGER'S DOOR OUTER HANDLE
FRONT PASSENGER'S FOOTWELL LIGHT
FRONT PASSENGER'S POWER WINDOW SWITCH
FUEL PUMP DRIVER UNIT
FUEL TANK UNIT SHIELD
FUSE/RELAY HOLDER C
GRY WIRE
HEATED WINDSHIELD WIPER AREA
HOOD LATCH SWITCH
HORN (HIGH)
LEFT FOG LIGHT
LEFT REAR DOOR INNER HANDLE LIGHT
LEFT REAR DOOR LATCH
LEFT REAR DOOR OUTER HANDLE
LEFT REAR POWER WINDOW SWITCH
LEFT REAR SEAT BACK HEATER
LEFT REAR SEAT CUSHION HEATER
MASTER LIGHTING CONTROL UNIT
MULTI VIEW CAMERA UNIT
PARKING, BACKUP SENSOR CONTROL UNIT
PASSENGER'S INSTRUMENT PANEL AMBIENT LIGHT
POWER DISTRIBUTION MODULE
RIGHT BSI ALERT INDICATOR
RIGHT FOG LIGHT
RIGHT POWER MIRROR
SECONDARY FUEL GAUGE SENDING UNIT SHIELD
THERMAL JOINT 8
TRANSMISSION CONTROL MODULE (TCM)
VSA MODULATOR CONTROL UNIT
W/ KEYLESS ACCESS
W/O MULTI VIEW CAMERA SYSTEM W/ MULTI VIEW CAMERA SYSTEM
WINDSHIELD WIPER CONTROL UNIT/MOTOR
Go to component -> Ground distribution circuit (2 of 6) -> HEATED WINDSHIELD WIPER AREA
Wiring diagram heated windshield wiper area (2 of 2)
BLK WIRE
BODY CONTROL MODULE
BRN WIRE
FUSE 14
FUSE 2-4
FUSE 36
FUSE/RELAY HOLDER B
GRN WIRE
GRY WIRE
HEATED WINDSHIELD WIPER AREA
HEATED WINDSHIELD WIPER AREA RELAY
HEATED WINDSHIELD WIPER AREA SWITCH
HOT AT ALL TIMES
HOT W/
MULTI VISOR SWITCH
OFF
PPL
RED WIRE
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
Go to component -> Wiper deicer circuit -> HEATED WINDSHIELD WIPER AREA
