Acura TLX II (2020-2024) fuel tank unit shield Wiring diagram
This page shows the only wiring diagram for the component.fuel tank unit shield, which is found in the car Acura TLX II (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuel tank unit shield (1 of 1)
ADAPTIVE DAMPER CONTROL UNIT
BLK WIRE
BRAKE FLUID LEVEL SWITCH
BRAKE PEDAL STROKE SENSOR SHIELD
CAN GATEWAY
CENTER CONSOLE ACCESSORY POWER SOCKET
CLIMATE CONTROL UNIT
DC-DC CONVERTER
DC-DC CONVERTER ACC RELAY
DRIVER'S FOOTWELL LIGHT
DRIVER'S INSTRUMENT PANEL AMBIENT LIGHT
EPS CONTROL UNIT
FRONT PASSENGER'S DOOR AMBIENT LIGHT
FRONT PASSENGER'S DOOR INNER HANDLE LIGHT
FRONT PASSENGER'S DOOR LATCH
FRONT PASSENGER'S DOOR OUTER HANDLE
FRONT PASSENGER'S FOOTWELL LIGHT
FRONT PASSENGER'S POWER WINDOW SWITCH
FUEL PUMP DRIVER UNIT
FUEL TANK UNIT SHIELD
FUSE/RELAY HOLDER C
GRY WIRE
HEATED WINDSHIELD WIPER AREA
HOOD LATCH SWITCH
HORN (HIGH)
LEFT FOG LIGHT
LEFT REAR DOOR INNER HANDLE LIGHT
LEFT REAR DOOR LATCH
LEFT REAR DOOR OUTER HANDLE
LEFT REAR POWER WINDOW SWITCH
LEFT REAR SEAT BACK HEATER
LEFT REAR SEAT CUSHION HEATER
MASTER LIGHTING CONTROL UNIT
MULTI VIEW CAMERA UNIT
PARKING, BACKUP SENSOR CONTROL UNIT
PASSENGER'S INSTRUMENT PANEL AMBIENT LIGHT
POWER DISTRIBUTION MODULE
RIGHT BSI ALERT INDICATOR
RIGHT FOG LIGHT
RIGHT POWER MIRROR
SECONDARY FUEL GAUGE SENDING UNIT SHIELD
THERMAL JOINT 8
TRANSMISSION CONTROL MODULE (TCM)
VSA MODULATOR CONTROL UNIT
W/ KEYLESS ACCESS
W/O MULTI VIEW CAMERA SYSTEM W/ MULTI VIEW CAMERA SYSTEM
WINDSHIELD WIPER CONTROL UNIT/MOTOR
Go to component -> Ground distribution circuit (2 of 6) -> FUEL TANK UNIT SHIELD
