Acura TLX II (2020-2024) driver's seat- back heater Wiring diagram
This page shows the only wiring diagram for the component.driver's seat- back heater, which is found in the car Acura TLX II (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's seat- back heater (1 of 1)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BREAKER
BRN WIRE
CLIMATE CONTROL SWITCH
CLIMATE CONTROL UNIT
COMPUTER DATA LINES SYSTEM
DC-DC CONVERTER (LEFT END OF DASH)
DRIVER'S SEAT CUSHION BLOWER MOTOR
DRIVER'S SEAT CUSHION HEATER
DRIVER'S SEAT- BACK HEATER
DRIVER'S SEAT-BACK BLOWER MOTOR
FRONT PASSENGER'S SEAT BACK HEATER
FRONT PASSENGER'S SEAT CUSHION BLOWER MOTOR
FRONT PASSENGER'S SEAT CUSHION HEATER
FRONT PASSENGER'S SEAT-BACK BLOWER MOTOR
FRONT SEAT HEATER/ VENTILATED SEAT CONTROL UNIT
FUSE 14
FUSE 4-1
FUSE 49
FUSE 5
FUSE/RELAY HOLDER C
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
LT BLU WIRE
PNK WIRE
POWER DISTRIBUTION MODULE
PPL
REAR SEAT HEATER CONTROL UNIT
RED WIRE
SEAT HEATER SWITCH
SEAT HEATER SWITCH IND
SMART FET
TAN WIRE
THERMISTOR
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Front ventilation & heated seat circuit -> DRIVER'S SEAT- BACK HEATER
