Acura TLX II (2020-2024) driver's power seat control unit Wiring diagram
This page shows the only wiring diagram for the component.driver's power seat control unit, which is found in the car Acura TLX II (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's power seat control unit (11 of 11)
2.0L TURBO
BLK WIRE
BRN WIRE
DRIVER'S POWER SEAT CONTROL UNIT
DRIVER'S SEAT POWER LUMBAR SUPPORT MOTOR A
DRIVER'S SEAT POWER LUMBAR SUPPORT MOTOR B
ELECTRIC SERVO BRAKE CONTROL UNIT/ PEDAL FEEL SIMULATOR
FRONT PASSENGER POWER SEAT CONTROL UNIT
FRONT PASSENGER SEAT HEIGHT MOTOR
FRONT PASSENGER SEAT LEFT BOLSTER MOTOR
FRONT PASSENGER SEAT POWER THIGH SUPPORT MOTOR
FRONT PASSENGER SEAT RECLINE MOTOR
FRONT PASSENGER SEAT RIGHT BOLSTER MOTOR
FRONT PASSENGER SEAT SLIDE MOTOR
FRONT PASSENGER SEAT TILT MOTOR
FRONT PASSENGER'S SEAT BACK HEATER
FRONT PASSENGER'S SEAT CUSHION HEATER
GRY WIRE
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
NCA WIRE
PCM
REAR WINDOW DEFOGGER
RIGHT FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH
ROCKER ARM OIL CONTROL SOLENOID
THERMAL JOINT 2
THERMAL JOINT 3
VTC OIL CONTROL SOLENOID VALVE A
VTC OIL CONTROL SOLENOID VALVE B
Go to component -> Ground distribution circuit (5 of 6) -> DRIVER'S POWER SEAT CONTROL UNIT
