Acura TLX II (2020-2024) camera circuits) Wiring diagrams
This page contains all the electrical diagrams for the component. camera circuits), in which he is found in the car Acura TLX II (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
camera circuits) wiring diagram (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
CAMERA CIRCUITS)
CENTER DISPLAY UNIT
CIRCUIT
COMPUTER DATA
FUSE 32
FUSE 36
FUSE 4
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
HOT W/ ACC RELAY ENERGIZED
JUNCTION BOX B
JUNCTION BOX C
LINES SYSTEM
LT BLU WIRE
LT GRN WIRE
NAVIGATION
NAVIGATION SYSTEM
NCA WIRE
PNK WIRE
PPL
REAR CAMERA CIRCUIT
RED WIRE
SYSTEM
TAN WIRE
TEL ANTENNA (PRIMARY)
TEL ANTENNA (SECONDARY)
TOUCHPAD UNIT
UNDER-DASH FUSE/RELAY BOX
USB CHARGER UNIT
USB PORT B (CHARGE ONLY)
VOLUME, SEEK SWITCH
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit, 17 speakers (2 of 6) -> CAMERA CIRCUITS)
camera circuits) wiring diagram (2 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
CAMERA CIRCUITS)
CENTER DISPLAY UNIT
CIRCUIT
COMPUTER DATA
FUSE 32
FUSE 36
FUSE 4
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
HOT W/ ACC RELAY ENERGIZED
JUNCTION BOX B
JUNCTION BOX C
LINES SYSTEM
LT BLU WIRE
LT GRN WIRE
NAVIGATION
NAVIGATION SYSTEM
NCA WIRE
PNK WIRE
PPL
REAR CAMERA CIRCUIT
RED WIRE
SYSTEM
TAN WIRE
TEL ANTENNA (PRIMARY)
TEL ANTENNA (SECONDARY)
TOUCHPAD UNIT
UNDER-DASH FUSE/RELAY BOX
USB CHARGER UNIT
USB PORT B (CHARGE ONLY)
VOLUME, SEEK SWITCH
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, 17 speakers (2 of 6) -> CAMERA CIRCUITS)
